Ammann AV130X Workshop Manual Articulated Tandem Roller From SN4022098 manuals in PDF

Factory Workshop Manual For Ammann Articulated Tandem Roller. Manual Contains Illustrations, Instructions, Diagrams For Step By Step Remove And Install, Assembly And Disassembly, Service, Inspection, Repair, Troubleshooting, Tune-Ups.

Format: PDF
Language: English, Czech
Quantity of Manuals: 2
Pages: 230; 230
Issued: january 2016
Bookmarks: Yes
Searchable: Yes
Wiring Diagrams: Yes
Hydraulic Diagrams: Yes

Model

Ammann Articulated Tandem Roller
AV130X
Tier 3
From SN 4022098

Contents

INTRODUCTION
-SAFETY PRECAUTIONS AND INSTRUCTIONS
Safety Regulations
Ecological Measures & Hygienic Principles
Fire Measures
MACHINE DESCRIPTION
-SPECIFICATION MANUAL
Basic Specification
Machine Dimension Scheme
Technical Data
-SPECIFICATION OF FLUIDS
Engine Oil
Fuel
Coolant
Hydraulic Oil
Gearbox Oil
Lubricating Grease
Windshield Washer Liquid
Drum Cooling Liquid
Air-Conditioning Filling
Fills
LUBRICATION AND MAINTENANCE CHART
-DRUM
How To Dismantle Vibration Hydraulic Motor
How To Dismantle Travel Hydraulic Motor
How To Dismantle Aux. Transmission
How To Dismantle Front Drum
How To Replace Drum’s Rubber Mounting
-KNUCKLE STEERING
How To Remove Steering Joint
How To Change Steering Joint Bearings
Remove Rotator’s Bearings
-HYDRAULICS
How To Dismantle Cooling Hydraulic Motor
How To Dismantle Steering Gear Pump
How To Dismantle Tandem Pump For Travel And Vibration
-REMOVING HYDRAULIC CYLINDERS FOR STEERING AND CRAB
Remove Hydraulic Cylinders For Steering And Crab
Remove Sealants Of Hydraulic Cylinders For Steering And Crab
BONNET REMOVAL
ENGINE REMOVAL
REMOVAL OF COOLERS
-CABIN
Heater Removal
Blower Removal
Wiper Motor Removal
Seat Switch
Position Sensor For Neutral And Parking Brake
LH Side Control Panel, Backing Horn Sensor
Seat Platform
Power-Assisted Steering
-WIRING
Fuses
Accumulator
Alternator
Starter
Layout Of Wiring Elements Within The Machine
-ANNEXES
Measuring The Relief Pressures Of Hydraulic Circuit
Vibration Frequency Adjustment
Adjust Pulse Sensors
Wiring Diagram
Electric Installations Cable Harnesses
Hydraulics Diagram
Check Bolted Connections Are Tightened
List Of Jigs
Hand Signals

What you get

You will receive PDF file with high-quality manual on your email immediately after the payment.
