Case 1107EX Operators Manual Soil Compactor 51435044 manuals in PDF

Factory Operators Manual For Case Soil Compactor. Manual For Owners And Operators. It Contains Important Information And Instructions For Maintenance Description Of The Functions And Capabilities Of The System. Description Of Possible Faults / Problems And Their Solution.

Format: PDF
Language: English
Pages: 170
Number: 51435044 (march 2018)
Bookmarks: Yes
Searchable: Yes

Model

Case Soil Compactor
1107EX

Contents

-GENERAL INFORMATION
Foreword
Intended Use
Note To The Owner
Product Identification Number (PIN) Plate
Component Identification
Main Components Of The Machine
-SAFETY INFORMATION
Note To The Owner
Personal Safety
Safety Rules
General Safety Rules
Transmission – Hand Signals
Welding On The Machine
Fuel System Maintenance
Cooling System Maintenance
Hydraulic System Maintenance
Tools And Equipment
Machine Safety Sign Information
Decal Information
-CONTROLS AND INSTRUMENTS
Access To Operator’s Platform
Operator’s Seat
Forward Controls
Overhead Controls
Cab Controls And Adjustments
-OPERATING INSTRUCTIONS
Commissioning The Unit
Starting The Unit
Stopping The Unit
Moving The Unit
-TRANSPORT OPERATIONS
Preparing For Road Transport
Shipping Transport
Recovery Transport
-WORKING OPERATIONS
General Information
Working Operations
-MAINTENANCE
General Information
Maintenance Planning
Every 10 Hours Of Operation Or Daily (Whichever Occurs First)
First 50 Hours
Every 100 Hours
Every 250 Hours
Every 500 Hours
Every 1000 Hours
Every 2000 Hours
As Required
Storage
Machine Disposal
-TROUBLESHOOTING
Fault Code Resolution
-SPECIFICATIONS
Technical Feature Of The Machine
General Specifications
Engine Specifications
Travel Hydraulic System
Vibration Hydraulic System
Steering System
Electrical System
Heating, Ventilation, And Air-Conditioning (HVAC) Unit – General Specification
Brakes
Capacities
Fuse And Relay Box – General Specification
Machine Operation
Special Torques
Torque Specifications
-ACCESSORIES
Telematics – Overview With Eagle Eye
Padded Drum Shell (Optional)

What you get

You will receive PDF file with high-quality manual on your email immediately after the payment.
