Factory Service Manual For Case Big Roll Baler. Manual Contains Illustrations, Instructions, Diagrams For Step By Step Remove And Install, Assembly And Disassembly, Service, Inspection, Repair, Troubleshooting, Tune-Ups.
Format: PDF
Language: English
Pages: 69
Number: GSS-1459-1
Model
Case Big Roll Baller
241
2400
Contents
-ADJUSTMENTS
Press Roll
Main Drive Chain Setting
Press Roll
Main Drive Chain Setting
Serial No 7811 and above
Rear Gate Stops
Cam Track
Lower Belt
Twine Tube and Knife
-SERVICE PROCEDURE
Power Take-Off Drive Train
-HYDRAULIC SYSTEM
Opening the Rear Gate
Closing the Rear Gate
Baling
Shop Test Procedure
Field Test Procedure
Components
MAIN DRIVE DOUBLE SPROCKET
PICK-UP ASSEMBLY
SLIP CLUTCH
WHEELS
BALE ROLL REMOVAL
-BELT SERVICING
Upper Belts
Splicing
Lower Belt
TROUBLESHOOTING
-41 BALE UNROLLER
Unroller Drum Drive Chain Adjustment
Hydraulic System
