Factory Service Manual For Case Magnum Rowtrac PST Tractor. Manual Contains Illustrations, Instructions, Diagrams For Step By Step Remove And Install, Assembly And Disassembly, Service, Inspection, Repair, Troubleshooting, Tune-Ups.
Format: PDF
Language: English
Pages: 5611
Number: 48115477 (April 2017)
Bookmarks: Yes
Searchable: Yes
Wiring Diagrams: Yes
Hydraulic Diagrams: Yes
Model
Case Tractor
Magnum 250
Magnum 280
Magnum 310
Magnum 340
Magnum 310 Rowtrac
Magnum 340 Rowtrac
Powershift Transmission (PST)
PIN ZGRF05001 and above
PIN ZHRF01001 and above
Magnum™ 250 PST TIER 2 [ZGRF05001 – ], Magnum™ 2654 PST TIER 3 [ZGRF05001 – ], Magnum™ 280 PST TIER 2 [ZGRF05001 – ], Magnum™ 310 PST TIER 2 [ZGRF05001 – ], Magnum™ 310 Rowtrac™ PST TIER 2 [ZGRF05001 – ], Magnum™ 3154 PST TIER 3 [ZGRF05001 – ], Magnum™ 340 PST TIER 2 [ZGRF05001 – ], Magnum™ 340 Rowtrac™ PST TIER 2 [ZGRF05001 – ]
