Case 300 400 SK Skid King Service Manual Log Skidder 9-73832 manuals in PDF

Factory Service Manual For Case  Skid King Log Skidder. Manual Contains Illustrations, Instructions, Diagrams For Step By Step Remove And Install, Assembly And Disassembly, Service, Inspection, Repair, Troubleshooting, Tune-Ups.

Format: PDF
Language: English
Pages: 505
Number: 9-73832
Bookmarks: Yes
Searchable: Yes
Wiring Diagrams: Yes

Model

Case Log Skidder
300 SK
400 SK

Contents

-SPECIFICATIONS AND ENGINE MAINTENANCE ON MODEL 300 SKID KING
Introduction
Specifications
Standard Torques
Removing Engine
Installing Engine
Air Cleaner
Cooling System
Engine Oil Filter
Radiator And Grille
Fuel System
-SPECIFICATIONS AND ENGINE MAINTENANCE ON MODEL 400 SKID KING
Introduction
Specifications
Removing Engine
Air Cleaner
Cooling System
Fuel System
Throttle Control Linkage, Exploded View
Engine Oil Filter
Torques
-HYDRAULIC SYSTEM ON MODELS 300 AND 400 SKID KING
Dozer-Steering Hydraulic Specifications
Hydraulic Diagrams
Torques For Hydraulic Fittings
Bleeding The Hydraulic System
Reservoir Oil Level
Trouble Shooting Chart
Testing Pump Output With A Flowmeter
Exploded Views
Vane Type Hydraulic Pump
Gear Type Hydraulic Pump
Manual Steering Pump
Cylinders
Dozer Control Valve
Remote Relief Valve
Return Line Filter
Magnetic Separator
Flow Control Valve
Hydraulic Oil And Diesel Fuel Tanks (Model 300 Skid King)
Hydraulic Oil Reservoir (Model 400 Skid King)
-ELECTRICAL SYSTEM AND INSTRUMENTS ON MODELS 300 AND 400 SKID KING
Tests And Adjustments
Alternator Charging System Precautions
Wiring Diagrams
Trouble Shooting Chart
Trouble Shooting The Starting Circuit,
Trouble Shooting The Charging Circuit
Batteries
Alternator Output Check
Belt Adjustment
Regulator Check
Adjusting Voltage Regulator
Adjusting Field Relay
Starter Check
Starter Solenoid Check
Instrument Panel, Model 300
Instrument Panel, Model 400
-BRAKE SYSTEM ON MODELS 300 AND 400 SKID KING
Diagram Of Brake System (Model 300 Skid King)
Exploded Views Of Brake System
Master Cylinder
Brake Lock
Brake Head
Relief Valve
Bleeding The Brakes
Parking Brake
-TORQUE CONVERTER ON MODEL 300 SKID KING
Specifications
Serial Number Location
Description (Including Operating Principles)
Preventive Maintenance
Trouble Shooting – Hydraulics
Trouble Shooting Chart
Servicing
-TRANSMISSION ON MODEL 300 SKID KING
Specifications
Servicing Transmissions S/N 5255 Up
Servicing Transmissions S/N 5133-5247
Bending Shift Lever
-14-INCH TRACTIO CLUTCH ON MODEL 300 SKID KING
Description
Specifications
Servicing
-TRANSFER CASE ON MODEL 300 SKID KING
Servicing The Transfer Case
-DRIVE SHAFTS AND UNIVERSAL JOINTS ON MODEL 300 AND 400 SKID KING
Trouble Shooting
Servicing
Drive Shaft Assembly
-TRANSMISSION REMOVAL AND INSTALLATION/TRANSMISSION PRESSURE LINE FILTER/TRANSMISSION CONTROLS ON MODEL 400 SKID KING
-TRANSMISSION
General Information
Description And Operation
Preventive Maintenance
General Overhaul Information
Disassembly Of Transmission Into Subassemblies
Rebuild Of Subassemblies
Assembly Of Transmission From Subassemblies
Wear Limits And Spring Data
-PLANETARY AXLES AND DIFFERENTIALS ON MODELS 300 AND 400 SKID KING
Introduction
Servicing The Differential
Planetary Ends Of Axle Shafts
-FRAMES ON MODELS 300 AND 400 SKID KING
Separating Front And Rear Frames
Oscillation (Hinge) Tube
Fairlead Bearings
Canopy And Exhaust System
-MODEL 19 WINCH ON MODELS 300 AND 400 SKID KING
Introduction
Trouble Shooting
Servicing

What you get

You will receive PDF file with high-quality manual on your email immediately after the payment.
