Factory Service Manual For Case Series Tractor. Manual Contains Illustrations, Instructions, Diagrams For Step By Step Remove And Install, Assembly And Disassembly, Service, Inspection, Repair, Troubleshooting, Tune-Ups.
Format: PDF
Language: English
Pages: 678
Number: 7-69124 (march 1995)
Bookmarks: Yes
Model
Case Tractor
3200
4200
Contents
-GENERAL
Safety Rules, General Information and Torque Specifications
General Specifications and Torques4
-ENGINE
Engine Removal
Cylinder Head
Cylinder Block
Lubrication System
Cooling System
-FUEL SYSTEM
Fuel System and Filters
Fuel Injection Pump
Fuel Injectors
ELECTRICAL
Electrical Troubleshooting and Schematics
Electrical Troubleshooting and Schematics (For Tractors from PIN JJE0918096)
Instrument Cluster Programming (For Tractors Equipped with 1983576C6 or
1983577C6 Instrument Clusters)
Battery Servicing and Testing
-STEERING
Steering Hand Pump
2WD Steering Cylinder (For Tractors prior to PIN JJE0906096)
2WD Steering Cylinder (For Tractors from PIN JJE0906096)
Front Axle – 2WD Tractors
-TRANSMISSION
Transmission Cross Sectional Drawings
Engine Clutch and Flywheel (Rockford 12 inch and Laycock 11 inch)
Separating the Tractor (between Engine and Speedbox)
Range Transmission Removal
Speed Transmission Removal
Speed Transmission Servicing
Powershift Transmission
Forward and Reverse Transmission
Creep Transmission
Range Transmission (For Tractors equipped with MFD)
Range Transmission (For 2WD Tractors)
MFD Transfer Gearbox, Drive Shaft and Parking Brake
Rear Axles
Differential
Steering Support (For Cab Tractors)
Steering Support (For Non-Cab Tractors)
PTO
Shiftable PTO
MFD Axle
-BRAKES
Parking Brake (For 2WD Tractors)
Rear Brakes (For Tractors prior to PIN JJE0908037)
Rear Brakes (For Tractors from PIN JJE0908037)
Brake Master Cylinder
-HYDRAULICS
Hydraulic Troubleshooting and Schematic
Hydraulic Hitch Adjustments
Multi Control Valve and Hydraulic Pump
Unloading and Flow Control Valve
Remote Valves
Hydraulic Housing Servicing
Hydraulic Housing Removal
Differential Lock Cylinder and Solenoid Valve
-CHASSIS AND MOUNTED EQUIPMENT
Pedal, Lever and Switch Adjustments
Air Conditioner Troubleshooting for Systems with HFC-134a Refrigerant (Visual and Operating)
Air Conditioner System Gauges and Testing
for Systems with HFC-134a Refrigerant
Air Conditioner System Service for Systems with HFC-134a Refrigerant
Air Conditioner System Component Servicing for Systems with HFC-I34a Refrigerant
XL Cab Removal
Low Profile Cab Removal
Seat Platform and Fenders
XL Cab Servicing
LP Cab Servicing
Hood and Panels
What you get
You will receive PDF file with high-quality manual on your email immediately after the payment.
