Case 7240 8240 9240 Axial Flow Tier 4B Final Service Manual Combine 48144050
The “Case 7240 8240 9240 Axial Flow Tier 4B Final Service Manual Combine 48144050” is an essential and comprehensive guide designed for professionals and technicians working with Case Combine models AXIAL-FLOW 7240, 8240, and 9240. This service manual, issued in August 2017 and cataloged under the number 48144050, is a meticulously detailed document spanning 8391 pages, available in PDF format, and written in English.
Key Features
Comprehensive Coverage
The manual covers a broad range of topics crucial for maintaining and servicing the Case Combine models. Each section is packed with illustrations, instructions, and diagrams to facilitate step-by-step procedures for removal, installation, assembly, disassembly, service, inspection, repair, troubleshooting, and tune-ups.
Detailed Contents
The manual is systematically divided into various sections to help users quickly find the information they need. Here are some of the key contents:
Introduction
The introductory section sets the stage for understanding the various systems and components of the combine. It provides an overview of the manual’s layout and the structure of the information presented.
Engine
This section dives into the intricate details of the engine and its components, including the crankcase, air cleaners, fuel tanks, manifolds, lubrication, cooling systems, aftercooler, fan drive, air screen, air compressor, and the Selective Catalytic Reduction (SCR) exhaust treatment.
Main Gearbox and Drive
Covers the main gearbox and its drive mechanisms, ensuring smooth operation and understanding of the power transmission.
Transmission
Explores the mechanical transmission hydraulic components, external controls, gearbox internal components, and differential.
Axle Systems
Details both the front and rear axle systems, including powered and non-powered configurations, final drives, and steering components.
Hydrostatic Drive
Provides insights into the hydrostatic drive components, including transmission and steering controls, two-speed assembly, pump and motor components.
Power Take-Off (PTO)
Focuses on the front PTO, explaining its mechanisms and maintenance.
Brakes and Controls
Details the parking brake or lock, hydraulic service brakes, ensuring safety and control.
Hydraulic Systems
Thoroughly explains various hydraulic systems within the combine, including pump control valves, auxiliary pumps, reservoirs, coolers, and filters.
Steering
Explores steering controls, tie rods, hydraulic components, cylinders, and autoguidance systems.
Wheels and Tracks
Provides detailed information on front wheels, tracks, track suspension, and related components.
Cab Climate Control
Explains the heating, ventilation, and air conditioning systems, ensuring a comfortable operator environment.
Electrical Systems
A comprehensive section on the electrical systems, covering fuel injection, cooling, oil, intake and exhaust systems, control systems, speed and position sensors, braking systems, HVAC controls, and extensive details on harnesses, connectors, lighting, alarms, instruments, and various control systems.
Additional Features
- Bookmarks: The PDF is bookmarked for easy navigation.
- Searchable: The text is searchable, making it easy to find specific information quickly.
- Wiring Diagrams: Detailed wiring diagrams are included to assist in troubleshooting and repairs.
- Hydraulic Diagrams: Extensive hydraulic diagrams provide a clear understanding of the fluid systems.
Applicability
This manual applies to the Case Combine models AXIAL-FLOW 7240, 8240, and 9240, specifically for Tier 4B final emissions standards. It includes specific information for models from PIN YEG227001 to YHG235000, ensuring that it covers a wide range of production units.
Conclusion
The “Case 7240 8240 9240 Axial Flow Tier 4B Final Service Manual Combine 48144050” is an indispensable resource for anyone involved in the service and maintenance of these advanced agricultural machines. With its detailed illustrations, clear instructions, and comprehensive coverage of all systems and components, this manual ensures that technicians can perform their tasks efficiently and effectively, ensuring the longevity and optimal performance of the combines.
