Case 821F 921F Operators Manual Wheel Loader 47535462 manuals in PDF

Factory Operators Manual For Case Wheel Loader. Manual For Owners And Operators. It Contains Important Information And Instructions For Maintenance Description Of The Functions And Capabilities Of The System. Description Of Possible Faults / Problems And Their Solution.

Format: PDF
Language: English
Pages: 328
Number: 47535462 (october 2014)
Bookmarks: Yes
Searchable: Yes

Model

Case Wheel Loader
821F
921F

Tier 2

Contents

-GENERAL INFORMATION
Note To The Owner
Electro-Magnetic Compatibility (EMC)
Product Identification
Operator’s Manual Storage On The Machine
Machine Orientation
Identification Of Machine Components
-SAFETY INFORMATION
Safety Rules And Signal Word Definitions
Personal Safety
Safety Rules
Seat Belts
Support Strut And Service Link
Utility Safety
Hand Signals
Safety Signs
-CONTROLS AND INSTRUMENTS
Access To Operator’s Platform
Operator’s Seat
Forward Controls
Left-Hand Side Controls
Right-Hand Side Controls
Exterior Controls
Instrument Cluster
Side Console
Climate Controls
-OPERATING INSTRUCTIONS
Commissioning The Unit
Starting The Unit
Stopping The Unit
Moving The Unit
-TRANSPORT OPERATIONS
Road Transport
Recovery Transport
-WORKING OPERATIONS
Loader Operations
-MAINTENANCE
General Information
Maintenance Chart
Daily Inspection
Every 10 Hours
Every 50 Hours
Initial 100 Hours
Every 100 Hours
Every 250 Hours
Every 500 Hours
Every 1000 Hours
Every 1500 Hours
Every 2000 Hours
Every 4000 Hours
As Required
Electrical System
Storage
-SPECIFICATIONS
General Specifications
Lift Capacities – 821F And 921F Hydraulic Lift Capacities
Machine Specifications And Dimensions – 821F And 921F General Specifications
Weight Adjustments – Material Weights And Weight Adjustments
Torque Charts
Material Weights
-ACCESSORIES
General Accessories
Telematics
INDEX

What you get

You will receive PDF file with high-quality manual on your email immediately after the payment.
