Case CX14 Operators Manual Mini Excavator 6-37900NA manuals in PDF

Factory Operators Manual For Case Mini Excavator. Manual For Owners And Operators. It Contains Important Information And Instructions For Maintenance Description Of The Functions And Capabilities Of The System. Description Of Possible Faults / Problems And Their Solution.

Format: PDF
Language: English
Pages: 194
Number: 6-37900NA
Bookmarks: Yes
Searchable: Yes

Model

Case Mini Excavator
CX14

Contents

-SAFETY PRECAUTIONS
General Safety Information
Safety Precautions
Pre-Start Safety
Safety During Operation
Inspection & Maintenance Safety
Battery Safety
Warning Labels & Decals
Prohibited Machine Operation
End Of Work Shift Safety
Precautions For Transportation
Towing The Machine
-MACHINE FAMILIARIZATION
Familiarization
General Machine Nomenclature
Operator Cab Nomenclature
Component & Controls Nomenclature
Storage & Others
Seat Belt
-BASIC MACHINE OPERATION
Pre-Start Check
Starting And Stopping Machine Engine
Stopping Machine Engine
Inspection After Starting Machine Engine
Warming Up Engine
Machine Operation
Practices To Improve Efficiency
Machine Parking
Check & Confirmation After Work
Precautions After Operation
Measures After Emergency Stop
Locking Up With Key
Emergency Measures Against Sudden Failure Of Machine
Caution On Using Rubber Crawler Shoes
Machine Operation In Adverse Weather Conditions
Precautions When Storing The Machine For A Long Time
-MAINTENANCE
General Information
General Safety & Precautions
Lubricant, Fuel & Coolant Specifications
Filters & Elements, And Bucket
Accessory Tools
Torque Specifications For Capscrews & Nuts
Torque Specifications For Joints & Hydraulic Hoses
Installing Hydraulic Hose And Pipe Joint
Releasing Internal Pressure Of Hydraulic Oil System
Pressurizing Hydraulic Oil Tank
Bleeding Air In Fuel System
Replacement Of Rubber Crawler Shoe
Inspection And Maintenance Chart
When Required
8-Hour (Daily) Inspection And Maintenance
50-Hour (Weekly) Inspection And Maintenance
250-Hour (3-Month) Inspection And Maintenance
500-Hour (6-Month) Inspection And Maintenance
1000-Hour (12-Month) Inspection And Maintenance
2000-Hour Inspection And Maintenance
Inspection Maintenance Check List
-TRANSPORTATION
When Preparing Transportation Plans
Loading And Unloading the Machine
Securing the Machine
Lifting Procedures For The Machine Complete
-SPECIFICATIONS
Machine Dimensions
Attachment Working Ranges
Boom With Arm Cylinder
Arm & Standard Bucket
Arm
Bucket
Dozer
Crawler Shoe
Bucket Types
Performance Specifications
Machine & Components Weight
-TROUBLESHOOTING
Operating
Travel
Hydraulic
Gauge Cluster Display
Engine
-OPTIONAL EQUIPMENT
Operation Of Hydraulic Breaker And Nibbler
Safety Precautions
Periodic Inspection And Maintenance Interval
-SPECIFICATIONS (EPA ENGINE)
The EPA Regulations

What you get

You will receive PDF file with high-quality manual on your email immediately after the payment.
