Factory Operators Manual For Case Compact Crawler Excavator. Manual For Owners And Operators. It Contains Important Information And Instructions For Maintenance Description Of The Functions And Capabilities Of The System. Description Of Possible Faults / Problems And Their Solution.
Format: PDF
Language: English
Pages: 178
Number: 87722073 (issued 2007)
Bookmarks: Yes
Searchable: Yes
Model
Case Compact Crawler Excavator
CX50B
Tier 4
Contents
-GENERAL INFORMATION
To the Owner
Right, Left, Front, and Rear of the Machine
Machine Components
Identification Numbers
-SAFETY, DECALS, AND HAND SIGNALS
Safety Rules
Operator Precautions
Decals
Hand Signals
-INSTRUMENTS AND CONTROLS
Operator Cab and Operator Seat
Machine Access Compartments and Doors
Operator s Compartment Controls and Accessories
-OPERATING INSTRUCTIONS
Before Operating the Machine
Operating the Machine
Starting and Stopping Machine Engine
Starting and Stopping Machine Engine in Cold Climates
Control Decal
Basic Operation of Hydraulic Controls
Practices to Improve Efficiency
Hydraulic Breaker
Transportation
Machine Storage
-LUBRICATION, FILTERS, AND FLUIDS
Fluids and Filters
Lubricant Specifications
Use of Bio-Degradable Oils
-MAINTENANCE AND ADJUSTMENTS
General Information
General Safety
Releasing Pressure in the Hydraulic System
Lubrication and Maintenance Quick Reference Chart
Daily Inspection and Maintenance
50 hour maintenance:
250 Hour Maintenance
500 Hour Maintenance
1000 Hour Maintenance
1500 Hour Maintenance
2000 Hour Maintenance
5000 Hour Maintenance
Special Procedures
-ELECTRICAL
Electrical Components
Fuses
Fusible Starter Link
Batteries
Alternator
Starter Motor
Work Lamps
-SPECIFICATIONS
General Specifications
Lifting Capacities
Torque Specifications
INDEX
What you get
You will receive PDF file with high-quality manual on your email immediately after the payment.
