Case CX75SR CX80 Tier 3 Service Manual Crawler Excavator manuals in PDF

Factory Service Manual For Case Crawler Excavator. Manual Contains Illustrations, Instructions, Diagrams For Step By Step Remove And Install, Assembly And Disassembly, Service, Inspection, Repair, Troubleshooting, Tune-Ups.

Format: PDF
Language: English
Quantity of Manuals: 2
Pages: 666; 664
Number: 87676026ANA (august 2008); 87476005A (march 2008)
Bookmarks: Yes
Searchable: Yes
Wiring Diagrams: Yes
Hydraulic Diagrams: Yes

Model

Case Crawler Excavator
CX75SR
CXC80
Tier 3

Contents

-GENERAL INFORMATION
Safety, General Information And Standard Torque Data
General Specifications And Special Torque Setting
-ENGINE
Removal And Installation Of The Engine
Engine Specifications
Disassembly And Assembly Of The Engine
-FUEL SYSTEM
Removal And Installation Of The Fuel Tank
Fuel Engine System
-ELECTRICAL SYSTEM
Electrical And Engine Functions And Service Support
Electrical Equipment And Electrical Circuit Diagrams
-UNDERCARRIAGE
Removal And Installation Of Tracks
Rollers
Take-Up Roller
-DRIVE TRAIN
Removal And Installation Of The Drive Motor And Final Drive Transmission
Disassembly And Assembly Of The Drive Motor And Final Drive Transmission
Removal And Installation Of The Swing Motor And Swing Reduction Gear
Disassembly And Assembly Of The Swing Reduction Gear
-UPPERSTRUCTURE HYDRAULICS
Specifications, Troubleshooting, Checks And Hydraulic Pressure Settings
Removal And Installation Of The Hydraulic Reservoir
Removal And Installation Of The Main Hydraulic Pump
Removal And Installation Of The Main Hydraulic Control Valve – CX75SR
Removal And Installation Of The Main Hydraulic Control Valve – CX80
Removal And Installation Of The Attachment Cylinders
Removal And Installation Of The Hydraulic Swivel
Removal And Installation Of The Pilot Blocs
Disassembly And Assembly Of The Main Hydraulic Pump
Disassembly And Assembly Of The Main Hydraulic Control Valve – CX75SR
Disassembly And Assembly Of The Main Hydraulic Control Valve – CX80
Disassembly And Assembly Of The Attachment Cylinders
Disassembly And Assembly Of The Hand Control Levers
Disassembly And Assembly Of The Foot Control Levers
Disassembly And Assembly Of The Solenoid Valve Block
Disassembly And Assembly Of The Cushion Valve
Disassembly And Assembly Of The Hydraulic Swivel
Disassembly And Assembly Of The Swing Motor
Hydraulic Functions
Hydraulic Component Functions
-UPPERSTRUCTURE
Air Conditioning Unit
Large Size Hydraulic Schematics – CX75SR
Large Size Electrical Schematics – CX75SR
Large Size Hydraulic Schematics – CX80
Large Size Electrical Schematics – CX80

What you get

You will receive PDF file with high-quality manual on your email immediately after the payment.
