Factory Operators Manual For Case IH Tractor. Manual For Owners And Operators. It Contains Important Information And Instructions For Maintenance Description Of The Functions And Capabilities Of The System. Description Of Possible Faults / Problems And Their Solution.
Format: PDF
Language: English
Pages: 112
Number: 9-5418
Bookmarks: Yes
Wiring Diagrams: Yes
Model
Case IH Tractor
1410
Contents
Use of Manual and Photograph of Tractor
Safety Messages and Cartoons
ROPS Safety Messages
Warning Signs
Hand Signals
Tractor Identification
Specifications
Operating Instruments and Controls
Operating Levers and Pedals
Starting The Engine
Stopping The Engine
Powershift Transmission
Svnchromesh Transmission
Power Take Off (PTO)
Front Wheel Tread Positions 2WD
Front Wheel Tread Positions 4WD/ Rear Wheel Tread Positions PAVT Wheels
Rear Wheel Tread Positions
Ballast
Measuring Wheel Slip
Three Point Linkage
Stabilizer Bars
Telescopic Link Ends/ Mechanical Flotation
Top Link 4WD Tractors
Drawbar
Position of Levers for Depth Control
Operating with Depth Control/ Position of Levers for Height Control/ Operating with Height Control
Position of Levers with TCU
Operating with TCU
Double Acting Live Take off Valves
Single Acting Equipment/ Pipes and Couplers
Remote Cylinders (Collar Type)
Remote Cylinders (Clamp Type)
Remote Cylinders (Mechanical Stop)
Preventive Maintenance
Service Chart
Lubricants and Fuel Storage
Lubrication Chart
Front Axle Lubrication Chart 4WD
Daily Inspection
50 Hour Service
100 Hour Service
200/250 Hour Service
500 Hour Service
1000 Hour Service
Removing The Hood/ Removing The Grille
Cylinder Head Tightening/ Fuses
Alternator/ Battery
SAE Seven Point Connector Plug
Wiring Diagrams
What you get
You will receive PDF file with high-quality manual on your email immediately after the payment.
