Case IH Farmall 95U 105U 115U Operators Manual With Supplement Tractor 84498894 manuals in PDF

Factory Operators Manual With Supplement For Case IH Tractor. Manual For Owners And Operators. It Contains Important Information And Instructions For Maintenance Description Of The Functions And Capabilities Of The System. Description Of Possible Faults / Problems And Their Solution.

Format: PDF
Language: English
Pages: 402
Number: 84498894 (may 2012)
Bookmarks: Yes
Searchable: Yes

Model

Case IH Tractor
Farmall 95U
Farmall 105U
Farmall 115U

Contents

-GENERAL INFORMATION
Note To The Owner
EC Declaration Of Conformity
Commission Directive 2010/52/EU
Noise Level
Electro-Magnetic Interference (EMC)
International Symbols
Introduction
Operator’s Manual Storage
Tractor Intended Use
Ecology And The Environment
Identification Plates
Approval Data Plate
Component Identification
-SAFETY INFORMATION
Safety Rules
Safety Information
Air Conditioning Safety Regulations
Vehicle Vibration Levels
Cab Guard
Machine Stability
Personal Protective Equipment (PPE)
Tractor Jacking Points
Hazardous Chemicals
Burn Prevention
Fire Or Explosion Prevention
Getting In And Out Of The Machine
Emergency Exit
Wheel Chocks
Safety Signs
-CONTROLS/INSTRUMENTS
Access To Operator’s Platform
Operator’s Seat
Instructor’s Seat
Forward Controls
Left-Hand Side Controls
Right-Hand Side Controls
Exterior Controls
Display Settings
-OPERATING INSTRUCTIONS
Commissioning The Unit
Starting The Unit
Stopping The Unit
Moving The Unit
-TRANSPORT OPERATIONS
Road Transport
Recovery Transport
-WORKING OPERATIONS
2WD Or 4WD
Differential Lock
Remote Valves
Power Take Off (PTO)
Electronically Controlled Hydraulic Lift
Three Point Hitch
Towbar
Rear Tow Hitch
Maximum Permitted Loads
Wheels And Tires
Wheel Track Adjustment
Ballast
-MAINTENANCE
General Information
Maintenance Chart
As Required
At Warning Message Display
Every 10 Hours Or Daily
Every 50 Hours
Every 100 Hours
Every 300 Hours
Every 600 Hours
Every 1200 Hours Or Annually
Every 1200 Hours Or Two Years
1800 Hours Service
Every 3000 Hours
Electrical System
Storage
Fluids And Lubricants
PTO
-TROUBLESHOOTING
Fault Code Resolution
Alarm(S)
Symptom(S)
-SPECIFICATIONS
Dimensions And Weights
Technical Data
-ACCESSORIES
Radio
Front-End Loader
Joystick For Control Valves
Hydraulic Valve For Trailer Brakes
Mechanical Trailer Brake Bracket
-SUPPLEMENT TO OPERATOR’S MANUAL-CNH
Working Operations-Instructions For The Connection Of Hydraulic Pipes “Diverter”
Maintenance
Engine – Replace

What you get

You will receive PDF file with high-quality manual on your email immediately after the payment.
