Case IH JX60 JX70 JX80 JX90 JX95 Straddle Mount Operators Manual Tractor manuals in PDF

Factory Operators Manual For Case IH Tractor. Manual For Owners And Operators. It Contains Important Information And Instructions For Maintenance Description Of The Functions And Capabilities Of The System. Description Of Possible Faults / Problems And Their Solution.

Format: PDF
Language: English
Quantity of Manuals: 2
Pages: 191; 192
Issue: may 2006; august 2008
Bookmarks: Yes
Searchable: Yes

Model

Case IH Tractor
JX60
JX70
JX80
JX90
JX90
Straddle Mount

Contents

-TO THE USER
Introduction
Using This Manual
Communication For The User
Important Ecological Considerations
TRACTOR IDENTIFICATION DATA
-SAFETY REGULATIONS
Guards And Safety Covers
Safety Decals
Symbols
-CONTROLS AND INSTRUMENTS
Seat Adjustment
Instrument Panel
Instrument Console Controls
Operating Controls, Right-Hand Side
Operating Controls, Left-Hand Side
-OPERATING INSTRUCTIONS
Before Using The Tractor
Starting The Engine
Transmission With Range Gear – 30 km/H (19 mph) (12F+4R-Synchromesh)
Transmission With Range Gear And Shuttle – 30 km/H (19 mph) (12F+12R- Synchro Shuttle)
Transmission With Creeper And Shuttle – 30 km/H (19 Mph) (20F+12R – Synchro Shuttle)
Four Wheel Drive
Mechanical Differential Lock
-FIELD USE
Power Take-Off
Hydraulic Lift
Three-Point Linkage
Towing Equipment
Folding Roll Bar
Remote Control Valves
Hydraulic Trailer Brakes (Not Available In All Markets)
-TYRES, WHEELS TRACKS, BALLAST
Wheel Track Adjustment
Steering Angle Adjustment
Tyre Maintenance
Tyre Loading Information
Inflation Pressures
Tyre Combinations
Ballasting
Maximum Permitted Weight
-LUBRICATION, MAINTENANCE
Introduction
Access For Inspection And Maintenance
Products And Quantities For Refilling
Lubrication And Maintenance Table
Flexible Maintenance
When An Indicator Light Illuminates On The Dashboard
Every 10 Hours Of Work
Every 50 Hours Of Work
Every 300 Hours Of Work
Every 600 Hours Of Work
Every 900 Hours Of Work
Every 1200 Hours Or Every Year
Every 1200 Hours Of Work Or Every 2 Years
General Maintenance
Tractor Storage
Electrical System
Recommendations For Bodywork Maintenance
TROUBLESHOOTING
SPECIFICATIONS AND DATA
INDEX

What you get

You will receive PDF file with high-quality manual on your email immediately after the payment.
