Case IH Maxxum 5120 5130 5140 5150 Operators Manual Tractor JJF1050700- manuals in PDF

Factory Operators Manual For Case IH Tractor. Manual For Owners And Operators. It Contains Important Information And Instructions For Maintenance Description Of The Functions And Capabilities Of The System. Description Of Possible Faults / Problems And Their Solution.

Format: PDF
Language: English
Pages: 299
Issue: february 2009
Bookmarks: Yes
Searchable: Yes

Model

Case IH Tractor
Maxxum 5120
Maxxum 5130
Maxxum 5140
Maxxum 5150
P.I.N JJF1050700 and after

Contents

TO THE OWNER
-IDENTIFICATION NUMBERS/MACHINE COMPONENTS
Machine Components
-SAFETY/DECALS
Safety Rules
Intended Use
General Safety And Accident Prevention Regulations
Transporting Passengers
Operation
Leaving The Tractor
Implements
PTO Operation
Service
Basic Rule
Mounting And Dismounting Of Tractor
Safety Decals
Roll Over Protective Structure (ROPS)
-INSTRUMENTS/CONTROLS
Standard Instrument Cluster
Digital Instrument Cluster
Operating Controls
Operators Seat
-OPERATING INSTRUCTIONS
Before Starting The Engine
Run In Procedure
Service Indicator Lamps And Gauges
Seat Belt
Normal Starting Procedure
Stopping The Engine
Parking The Tractor
Cold Temperature Operation
Towing The Tractor
How To Transport The Tractor
Operating The Transmission
Differential Lock
Wheel Slip Indicator
Cab Air Flow Arrangements
Maximum Inside Cab Pressure
Maximum Air Flow And Maximum Cool
Maximum Heat
Air Conditioner Operation
Power Takeoff
Drawbar
Combined Auto Hitch And Drawbar
Tractor Amber Warning Lamps And Direction Turn Signals
-FIELD OPERATION
Drawbar Preparation
Quick Adjust, Height Adjustable, Clevis Type Trailer Hitches
Three Point Hitch System Preparation
Rear Hitch Operation
Hitch Operating Tips
Front Hitch Preparation
Remote Hydraulics Preparation
Remote Hydraulics Operation
Auxiliary Power Connections
Programming Digital Instrument Cluster
Foldable ROPS Frame
-TIRES/WHEELS/SPACING/BALLAST
Tire And Wheel Equipment
Tire And Wheel Service
MFD Front Wheel Tread Positions
Rear Wheel Tread Positions
Dual Rear Wheel Tread Positions
MFD Axle Adjustments
Rear Wheel Adjustment
Front Wheel Fenders
Front To Rear Tire Size Combinations
Tractor Ballast
-LUBRICATION/FILTERS/FLUIDS
Hourmeter
Hood And Side Panels
Toolbox
Grease Points
Capacities
Engine Lubrication
Fuel System
Cooling System
Air Induction System
Transmission Lubrication
Mechanical Front Drive (MFD) Axle
Front PTO Lubrication
Cab Air Filters
-MAINTENANCE/ADJUSTMENTS
Cooling System
Operators Cab
Auto Hitch Release Cable Adjustment
Auto Hitch Lift Rod Adjustment
Hitch Bolts
-ELECTRICAL SYSTEM
Electrical System
General Service Information
Batteries
Bulb And Lamp Replacement
MACHINE STORAGE
-SPECIFICATIONS
Diesel Engine
General Machine
Travel Speeds
Approximate Measurements And Weights
Noise Levels
Case Technical Manuals

What you get

You will receive PDF file with high-quality manual on your email immediately after the payment.
