Case IH Steiger Quadtrac 400 450 500 550 600 Tier 2 Operators Manual Tractor JEEZ00000FF314001- manuals in PDF

Factory Operators Manual For Case IH Tractor. Manual For Owners And Operators. It Contains Important Information And Instructions For Maintenance Description Of The Functions And Capabilities Of The System. Description Of Possible Faults / Problems And Their Solution.

Format: PDF
Language: English
Pages: 522
Issue: september 2017
Bookmarks: Yes
Searchable: Yes

Model

Case IH Tractor
Steiger 400, 450, 500, 550, 600
Quadtrac 450, 500, 550, 600
Tier 2
PIN JEEZ00000FF314001 and above

Contents

-GENERAL INFORMATION
Note To The Owner
Intended Use
CNH Industrial America LLC Technical Manuals
Your Tractor
Electro-Magnetic Compatibility (EMC)
Product Identification
Operator’s Manual Storage On The Machine
Machine Orientation
Component Location
-SAFETY INFORMATION
Safety Alert Symbol And Signal Word Definition
Safety Rules
Ecology And The Environment
Protective Structures
Hazardous Substances
Emergency Exit
Articulation Cylinder Locking Blocks
Safety Signs
-CONTROLS AND INSTRUMENTS
Access To Operator’s Platform
Operator’s Seat
Instructional Seat
Forward Controls
Right-Hand Side Controls
Rearward Controls
Overhead Controls
Exterior Controls
Instrument Cluster
-OPERATING INSTRUCTIONS
Commissioning The Unit
Starting The Unit
Stopping The Unit
Moving The Unit
Parking The Unit
-TRANSPORT OPERATIONS
Road Transport
Shipping Transport
Recovery Transport
-WORKING OPERATIONS
General Information
Rear Power Take-Off (PTO)
Three-Point Hitch
Drawbars And Towing Attachments
Trailer Brake Coupler
Auxiliary Power Connections
Hydraulic Remote Control Valves
Ballasting The Tractor
Front And Rear Axle
-MAINTENANCE
General Information
Maintenance Planning
At Warning Message Display
Every 10 Hours Or Daily
Every 50 Hours
First 100 Hours
Every 600 Hours
Every 600 Hours Or Yearly
Every 1000 Hours Or Yearly
Every 1200 Hours
Every 1800 Hours
Every 2400 Hours
Every 3000 Hours
As Required
Fuse And Relay Locations
Storage
-TROUBLESHOOTING
Fault Code Resolution
Alarm(S)
-SPECIFICATIONS
Engine Specifications
Power Train And Hydraulics
Lubricants And Capacities
Speed Charts – Powershift Transmission
Speed Charts – CVXdrive Transmission
Vehicle Dimensions And Shipping Weight
Maximum Operating Weight
-ACCESSORIES
Farming System Displays
Chemical Tank Mounting
General Accessories
