Factory Operators Manual For Case Skid Steer And Compact Track Loader. Manual For Owners And Operators. It Contains Important Information And Instructions For Maintenance Description Of The Functions And Capabilities Of The System. Description Of Possible Faults / Problems And Their Solution.
Format: PDF
Language: English
Pages: 282
Number: 47683888 (september 2014)
Bookmarks: Yes
Searchable: Yes
Model
Case Alpha Series Skid Steer Loader And Alpha Series Compact Track Loader
Alpha Series Skid Steer Loader
SR130
SR210
SR160
SR240
SR175
SV185
SV280
Tier 4B (final)
Alpha Series Compact Track Loader
TR270
TR310
Tier 4B Final
Contents
-GENERAL INFORMATION
Note To The Owner
Electro-Magnetic Compatibility (EMC)
Product Identification Number (PIN)
Machine Orientation
Machine Components
Emissions Overview
-SAFETY INFORMATION
Signal Word Definitions
Safety Rules
Utility Safety
Proper Entry And Exit
Starting And Stopping Precautions
Seat Belt Precautions
Specific Precautions To This Machine
Fire Extinguisher
Safety Rules – California Proposition 65 Warning
Roll Over Protective Structure (ROPS)
Welding On The Machine
Loader Arm Lock And Cab Tilt Procedure – Radial Lift Machines
Loader Arm Lock And Cab Tilt Procedure – Vertical Lift Machines
No Engine Power – Loader Arm Down Control
Emergency Exit
Machine Safety Sign Information
Safety Signs
-CONTROLS AND INSTRUMENTS
Access To Operator’s Platform
Operator’s Seat
Mechanical Hydraulic Controls
Electro-Hydraulic Controls
Control Levers
Auxiliary Hydraulics
Instrument Cluster
-OPERATING INSTRUCTIONS
Commissioning The Unit
Starting The Unit
Stopping The Unit
Moving The Unit
-TRANSPORT OPERATIONS
Shipping Transport
Recovery Transport
-WORKING OPERATIONS-GENERAL INFORMATION
Mechanical Attachment Mounting Systems
Hydraulic Attachment Mounting Systems
Field Operation
-MAINTENANCE
General Information
Maintenance Chart
Every 10 Hours Or Daily
Every 50 Hours
Every 250 Hours
Every 500 Hours
Every 1000 Hours
Every 2000 Hours
Every 4000 Hours
As Required
Storage
-TROUBLESHOOTING
Fault Code Resolution
-SPECIFICATIONS
General Specification
Material Weights
Units Of Measure And Conversion
Torque Charts – Minimum Tightening Torques For Normal Assembly
-ACCESSORIES
Telematics – Overview With Case Sitewatch
INDEX
What you get
You will receive PDF file with high-quality manual on your email immediately after the payment.
