Case WX145 WX165 WX185 Service Manual Hydraulic Excavator 9-91221 manuals in PDF

Factory Service Manual For Case Hydraulic Excavator. Manual Contains Illustrations, Instructions, Diagrams For Step By Step Remove And Install, Assembly And Disassembly, Service, Inspection, Repair, Troubleshooting, Tune-Ups.

Format: PDF
Language: English
Pages: 746
Number: 9-91221
Bookmarks: Yes
Searchable: Yes
Wiring Diagrams: Yes
Hydraulic Diagrams: Yes

Model

Case Hydraulic Excavator
WX145
WX165
WX185

Contents

-SAFETY INSTRUCTIONS
Preface
Safety Instructions
-TECHNICAL DATA AND SPECIAL TOOLS
Foreword
Data Sheet For Cylinders WX145
Data Sheet For Cylinders WX165
Data Sheet For Cylinders WX185
Bucket-Induced Protrusion
SI- And Additional Units
Conversions Tables
Tightening Torques
Calculation Examples
Special Tools For Cylinders
Special Tools For Axles And Gearboxes
Spacers
-MACHINE STRUCTURE
Machine Construction
-ELECTRICAL SYSTEM
The Electrical System
Electrical Circuit Diagrams, WX165, WX185, 8916247
Electrical Circuit Diagrams, WX165, WX185, 8916248
Electrical Circuit Diagrams For Supplementary Functions
-ELECTRONICS
Control
Electronic Control Unit
Power Supply
Components At Can Bus 1
Components At Can 2 Bus
ESX Coding
PCS: Power Control System
PCS Components
-HYDRAULICS
Control
Hydraulic System
Control Block
Pilot-Control System
Travel Circuit
Braking, Steering And Fan Circuit
Undercarriage, Stabilizers
Bucket Cylinder Circuit
Adjusting Cylinder Circuit
Combined Functions
Hydraulic Hammer Circuit With Boom Adjusting Equipment
Hammer Circuit With Auxiliary Function (Boom Adjusting Equipment)
Shears / Crusher Circuit (Boom Adjusting Equipment)
Hydraulic Hammer Circuit (Monoblock Boom Equipment)
Hammer Circuit And Auxiliary Function, Monoblock Equipment
Shears / Crusher Circuit, Mono Boom Equipment
Slewing System
-TROUBLESHOOTING AND REPAIR
Table Of Contents
Fault Codes
Fault Codes PCS Unit
Fault Codes, Central Unit
-REPAIR INSTRUCTIONS
Repair Instructions
Superstructure Components
Link Between Superstructure And Undercarriage Components

What you get

You will receive PDF file with high-quality manual on your email immediately after the payment.
