Factory Shop Manual For Daewoo 225NLC-V Hydraulic Excavator. Illustrations, instructions, diagrams for step by step remove and install, assembly and disassembly, service, inspection, repair, troubleshooting, tune-ups.
Format: PDF
Language: English
Pages: 684
Number: 023-00062E
Bookmarks: Yes
Searchable: Yes
Wiring Diagrams: Yes
Hydraulic Diagrams: Yes
Model
Daewoo Hydraulic Excavator
Solar 225NLC-V
Contents
-SAFETY
Track Excavator Safety
-SPECIFICATIONS
Specifications for Solar 225NLC-V
-GENERAL MAINTENANCE
General Maintenance Procedures
Standard Torques
-UPPER STRUCTURE
Cab
Counterweight
Fuel Tank
Fuel Transfer Pump
Swing Bearing
Swing Reduction Gearbox
-LOWER STRUCTURE AND CHASSIS
Track Assembly
-ENGINE AND DRIVE TRAIN
Air-Conditioner
Drive Coupling (Main Pump)
-HYDRAULICS
Hydraulic System Troubleshooting, Testing and Adjustment
Accumulator
Center Joint (Swivel)
Cylinders
Swing Motor
Travel Motor (With Gearbox) (GM35VL)
Main Pump (With Regulator)
Main Control Valve
Pilot Control Valve (Work Lever / Joystick)
Travel Control Valve (With Damper)
Hydraulic Schematic (Solar 225LC-V/225NLC-V)
-ELECTRICAL SYSTEM
Electrical System
Electrical Schematic (Solar 225LC-V/225NLC-V)
-ATTACHMENTS
Boom and Arm
Bucket
