JCB 1CX Operators Handbook Backhoe Loader 4200 manuals in PDF

Factory Operators Handbook For JCB Backhoe Loader. Manual For Owners And Operators. It Contains Important Information And Instructions For Maintenance Description Of The Functions And Capabilities Of The System. Description Of Possible Faults / Problems And Their Solution.

Format: PDF
Language: English
Pages: 108
Number: 4200 (may 1994)

Model

JCB Backhoe Loader
1CX

Contents

-INTRODUCTION
About this Handbook
The JCB 1CX
Safety First – Yours and Other Peoples
Safety Check List
Safety Decals
Identifying Your Machine
-OPERATION
Introduction
Before Entering the Cab
Entering/Leaving the Cab
Leaving the Cab in an Emergency
Door and Windows {Cab Machines only)
Cab Light (Cab Machines only)
Heater Controls (Cab Machines only)
Seat Controls
Seat Belt
Cab Layout
Controls, Switches and Instruments
Loader Controls
Stabiliser Controls
Backhoe Controls (JCB X Pattern)
Backhoe Controls (JCB + Pattern)
Backhoe Controls (ISO Pattern)
Hydraclamps
Foot Operated Pedal
Before Starting the Engine
Starting the Engine
Jump-Starting the Engine
Preparing the Machine for Travel
Rotating Beacon
Boom/Slew Lock
Testing the Parking Brake
Getting the Machine Moving
Stopping and Parking the Machine
Using the Attachments and Site Safety
Loader Quickhitch
Working with the Loader
Working with the Backhoe
Sideshifting the Backhoe
Operating in Low Temperatures
Operating in High Temperatures
Moving a Disabled Machine
Transporting the Machine
Emergency Lower Procedure
-MAINTENANCE
Lubricants – Health and Safety
Service Requirements
Service Schedules
Cleaning the Machine
Checking for Damage
ROPS/FOPS Structure
Loader Arm Safety Strut
Engine Compartment Access
Seat Belt
Greasing (10 Hours)
Lubrication
Engine Air Filter
Engine Oil and Filter
Engine Cooling System
Engine Alternator Belt
Drive Chain Lubrication
Drive Chain Tension
Fuel System
Hydraulic System
Battery
Electrical System
Tyres and Wheels
Fluids, Capacities and Lubricants
Windscreen Washer
Obtaining Replacement Parts
-OPTIONAL ATTACHMENTS
Introduction
Quick Release Couplings
Connecting/Disconnecting Hydraulic Hoses
Shovels
6 – in -1 Shovel
Pallet Forks
Manure/Silage Fork with Top Grab
Attachment Frame
-SPECIFICATIONS
Static Dimensions and Specifications
Optional Attachments
Noise and Vibration Data
Tipping Loads

What you get

You will receive PDF file with high-quality manual on your email immediately after the payment.
