JCB 3CX 4CX Manual Easy Controls Operators Manual Backhoe Loader 9811-4250 manuals in PDF

$14.95

Factory Operators Manual For JCB Backhoe Loader. Manual For Owners And Operators. It Contains Important Information And Instructions For Maintenance Description Of The Functions And Capabilities Of The System. Description Of Possible Faults / Problems And Their Solution.

Photo 8 - JCB 3CX 4CX Manual Easy Controls Operators Manual Backhoe Loader 9811-4250
JCB 3CX 4CX Manual Easy Controls Operators Manual Backhoe Loader 9811-4250 $14.95
  • Lifetime Free Access
  • Instant Downloads
  • Support and Instructions with download
Guaranteed Safe Checkout

Factory Operators Manual For JCB Backhoe Loader. Manual For Owners And Operators. It Contains Important Information And Instructions For Maintenance Description Of The Functions And Capabilities Of The System. Description Of Possible Faults / Problems And Their Solution.

Format: PDF
Language: English
Pages: 306
Number: 9811/4250 (february 2009)
Searchable: Yes

Model

JCB Backhoe Loader
3CX
4CX
SN from 1347278 to 1349999
Manual / Easy Controls

Contents

-SAFETY NOTICES
Important Information
-INTRODUCTION
About This Manual
Machine Description
Safety Check List
Safety Decals
Identifying Your Machine
Machine Security
-OPERATION
Introduction
Before Entering the Cab
Entering and Leaving the Cab
Doors and Windows
Seat Controls
Seat Belt
Visibility Aids
Cab Layout (Manual Controls)
Cab Layout (Easy Controls)
Drive Controls, Switches and Instruments
Operating Levers (Manual Controls)
Operating Levers (Easy Controls)
Safety Equipment
Before Starting the Engine
Starting The Engine
Preparing The Machine For Travel
Getting The Machine Moving
Stopping and Parking the Machine
Working With The Machine
Operating Environment
Refuelling the Machine
Moving A Disabled Machine
Transporting The Machine
Lifting A Machine
Storage of the Machine
-ROUTINE MAINTENANCE
Service Requirements
Health and Safety
Service Schedules
Fluids, Lubricants and Capacities
Tools
Prepare the Machine for Maintenance
Cleaning the Machine
Checking for Damage
Greasing
Access Panels 191
Heater and Air Conditioning
Brakes
Electrical System
Engine
Fuel System
Hydraulic System
Transmission
Tyres and Wheels
Wheel Alignment
Wear Pads
Windscreen Washer
Fire Extinguisher (if fitted)
-OPTIONAL ATTACHMENTS
Introduction
Attachments For Your Machine
Connecting/Disconnecting Hydraulic Hoses
Loader Quickhitch
Backhoe Quickhitch (Mechanical Type)
Directly Mounted Backhoe Attachments
Shovel – Forks Option
Tool Carrier and Forks Option
Hammer (If Fitted)
Hydraulic Tool Circuit (HTC)
Side Tip Shovel
-SPECIFICATIONS
Lifting (Object Handling) Regulations and Safe Working Loads
Backhoe Bucket Weights And Dimensions
Static Dimensions
Hydraulic Hose Burst Pressures
Noise Data
Vibration Data
Tyre Sizes And Pressures
Travel Speed
-WARRANTY INFORMATION
Machine Service Record Sheet
Registration Information
