Factory Operators Manual For JCB Backhoe Loader. Manual For Owners And Operators. It Contains Important Information And Instructions For Maintenance Description Of The Functions And Capabilities Of The System. Description Of Possible Faults / Problems And Their Solution.
Format: PDF
Language: English
Pages: 207
Number: 9831/2200-2 (February 2016)
Searchable: Yes
Model
JCB Backhoe Loader
3DX SN from 2517501 to 2532500
3DX Xtra SN from 1494400 to 1502999
3DX Super SN from 1494400 to 1502999
4DX SN 1415600 to 1416999
Contents
-SAFETY NOTICES
Important Information
-INTRODUCTION
About This Manual
Machine Description
Safety Check List
Identifying Your Machine
-OPERATION
Introduction
Before Entering the Cab
Entering and Leaving the Cab
Doors and Windows
Seat Controls
Seat Belt
Cab Layout
Drive Controls, Switches and Instruments
Air-Conditioning
Operating Levers
Travel Speed Modes
Safety Equipment
Before Starting the Engine
Starting The Engine
Preparing The Machine For Travel
Getting The Machine Moving
Stopping and Parking the Machine
Working With The Machine
Operating Environment
Refuelling the Machine
Moving A Disabled Machine
Transporting The Machine
Lifting A Machine
Storage of the Machine
Machine Security
-ROUTINE MAINTENANCE
Service Requirements
Health and Safety
Service Schedules
Fluids, Lubricants and Capacities
Tools
Prepare the Machine for Maintenance
Cleaning the Machine
Checking for Damage
Greasing
Access Panels
Air Conditioning
Brakes
Electrical System
Engine
Fuel System
Hydraulic System
Transmission
Tyres and Wheels
Wear Pads
Windscreen Washer (If Installed)
-OPTIONAL ATTACHMENTS
Introduction
Attachments For Your Machine
Connecting/Disconnecting Hydraulic Hoses
Directly Mounted Excavator Attachments
Shovel – Forks (If Installed)
Tool Carrier and Forks (If Installed)
-SPECIFICATIONS
Lifting Regulations and Safe Working Loads
Static Dimensions
Performance Dimensions
Hydraulic Hose Burst Pressures
What you get
You will receive PDF file with high-quality manual on your email immediately after the payment.
Reviews
There are no reviews yet
