JCB 530-70 532-120 533-105 535-60 535-95 535-125 535-140 537-135 540-70 540-140 540-170 Loadall Series II Operators Manual Telescopic Handler 9801-8980 manuals in PDF

Factory Operators Manual For JCB Loadall Telescopic Handler. Manual For Owners And Operators. It Contains Important Information And Instructions For Maintenance Description Of The Functions And Capabilities Of The System. Description Of Possible Faults / Problems And Their Solution.

Format: PDF
Language: English
Pages: 254
Number: 9801/8980 (may 2005)
Searchable: Yes

Model

JCB Loadall Telescopic Handler
530-70
SN from 1016569
532-120
SN from from 1036593 to 1065548
533-105
SN from 1036561
535-60
SN from 1064599
535-95
SN from 1036555
535-125
SN from 1064203
535-140
SN from 1065087
537-135
SN from 1036474 to 1064711
540-70
SN from 1016740
540-140
SN from 1064723
540-170
SN from 1037581

Series II

Contents

-INTRODUCTION
About this Handbook
Machine Description
Safety – Yours and Other People’s
Safety Check List
Safety Decals
Identifying Your Machine
JCB Immobiliser Option
-OPERATION
Introduction
Before Entering the Cab
Entering & Leaving the Cab, Doors and Windows
Seat Controls
Seat Belt
Cab Layout and Controls
Cab Switches and Instruments
Heater & Air Conditioning
Single Lever Control
Manual Auxiliary Control
Servo Control
Chassis Levelling (Sway) Option
Stabiliser Control Option
Before Starting the Engine
Starting the Engine
Preparing for Road Travel
Preparing for Site Travel
Smooth Ride System
Testing the Parking Brake
Getting the Machine Moving
Stopping and Parking the Machine
Using the Load Charts and Boom Indicators
Load Moment Indicator (LMI)
LC1 Load Control System
LC2 Load Control System
Working with the Machine
Operating in Low Temperatures
Operating in High Temperatures
Towing a Machine
Recovery Hitch
Mechanical Tow Hitch Option
Hydraulic Tow Hitch Option
Transporting the Machine
Lifting a Machine
-MAINTENANCE
Lubricants – Health and Safety
Service Requirements
Service Schedules
Boom Safety Strut
Engine Cover
Cleaning the Machine
Checking for Damage
Seat Belt
Greasing (General)
oiling
Brakes
Tyres And Wheels
Engine Air Filter
Engine Oil And Filter
Engine Cooling System
Fuel System
Transmission
Front And Rear Axle
Front And Rear Hub
Hydraulic System
Hose Burst Protection Valves
Battery
Jump-Starting the Engine
Electrical System
Heater and Air Conditioning Options
Windscreen Washer
Obtaining Replacement Parts
Fluids, Lubricants, Capacities and Specifications
Boom Wear Pad Clearance
-OPTIONAL ATTACHMENTS
Introduction
Quick Release Couplings
Installing and Removing Q-Fit Attachments
Hydraulic Pin Locking Option
Extension Jib
Fork Mounted Hook
Roof Truss Jib
Work Platforms
-SPECIFICATIONS
Static Dimensions
Performance Dimensions
Axle Weight Distribution
Engine Emissions
Tyres and Pressures
Trailer Towing Limitations
Noise and Vibration Data
Load Charts
SERVICE RECORD SHEET
REGISTRATION INFORMATION

What you get

You will receive PDF file with high-quality manual on your email immediately after the payment.
