Factory Service And Maintenance Manual For JLG Vertical Mast. Manual Contains Important Information And Instructions For Maintenance Description Of The Functions And Capabilities Of The System. Illustrations, Instructions, Diagrams For Step By Step Remove And Install, Assembly And Disassembly, Service, Inspection, Repair, Troubleshooting, Tune-Ups.
Format: PDF
Language: English
Quantity of Manuals: 2
Pages: 62
Issue: december 2000; april 2000
Bookmarks: Yes
Searchable: Yes
Wiring Diagrams: Yes
Hydraulic Diagrams: Yes
Model
JLG Scissor Lift
26MRT
Contents
-INTRODUCTION – MAINTENANCE SAFETY PRECAUTIONS
General
Hydraulic System Safety
Maintenance
-SPECIFICATIONS
Capacities
Component Data
Performance Data
Torque Requirements
Lubrication
Cylinder Specifications
Pressure Settings
Serial Number Locations
Limit Switches
Major Component Weights
Critical Stability Weights
-PROCEDURES
General
Servicing and Maintenance Guidelines
Lubrication Information
Cylinders – Theory of Operation
Valves – Theory of Operation
Component Functional Description
Wear Pads
Cylinder Checking Procedures
Lift Cylinder Removal and Installation
Lift Cylinder Repair
Steer Cylinder Repair
Tilt Alarm Switch Adjustment (If Equipped)
Limit Switch Adjustment
Pressure Setting Procedures
Drive Axle Repair
Brake Repair
Throttle Checks and Adjustments
Control Card Setup and Test Procedures
Valve Driver Card Setup Procedure
Preventive Maintenance and Inspection Schedule
-TROUBLESHOOTING
General
Troubleshooting Information
Hydraulic Circuit Checks
What you get
You will receive PDF file with high-quality manual on your email immediately after the payment.
