Factory Service And Maintenance Manual For JLG Vertical Mast. Manual Contains Important Information And Instructions For Maintenance Description Of The Functions And Capabilities Of The System. Illustrations, Instructions, Diagrams For Step By Step Remove And Install, Assembly And Disassembly, Service, Inspection, Repair, Troubleshooting, Tune-Ups.
Format: PDF
Language: English
Pages: 136
Issue: august 2007
Bookmarks: Yes
Searchable: Yes
Wiring Diagrams: Yes
Hydraulic Diagrams: Yes
Model
JLG Scissor Lift
320-30
Contents
-INTRODUCTION – MAINTENANCE SAFETY PRECAUTIONS
General
Hydraulic System Safety
Maintenance
-SPECIFICATIONS
Operating Specifications
Dimensional Data
Capacities
Engine
Tires
Torque Requirements
Sensors
Major Component Weights
Critical Stability Weights
Pressure Setting
Lubrication
-GENERAL
Machine Preparation, Inspection, and Maintenance
Service and Guidelines
Lubrication and Information
Operator Maintenance
Cylinder Drift Test
Preventive Maintenance and Inspection Schedule
-CHASSIS & SCISSOR ARMS
Operating Characteristics
Wheel Assembly
Steering Assembly
Rear Axle
Outrigger Cylinder Removal
Side Compartments
Platform
Ladder Installation
Scissor Arms
-HYDRAULICS
Cylinders – Theory of Operation
Valves – Theory of Operation
Cylinder Checking Procedure
Cylinder Repair
Valves
-JLG CONTROL SYSTEM
Operation and Technical Data On Control Card Complex 2
Automatic Self Leveling Device – (NIVOLUX)
Engine Control System (Circuit Board Code MC 536)
Load Sensing System (LSS)
-GENERAL ELECTRICAL INFORMATION & SCHEMATICS
General
Multimeter Basics
Applying Silicone Dielectric Compound To Amp Connectors
Working With Deutsch Connectors
Electrical Schematic
Hydraulic Diagram
