JLG Skytrak 6036 6042 8042 10042 10054 Service Manual Telehandler manuals in PDF

$19.95

Factory Service Manual For JLG Telehandler. Manual Contains Illustrations, Instructions, Diagrams For Step By Step Remove And Install, Assembly And Disassembly, Service, Inspection, Repair, Troubleshooting, Tune-Ups.

Photo 8 - JLG Skytrak 6036 6042 8042 10042 10054 Service Manual Telehandler
JLG Skytrak 6036 6042 8042 10042 10054 Service Manual Telehandler $19.95
  • Lifetime Free Access
  • Instant Downloads
  • Support and Instructions with download
Guaranteed Safe Checkout

Factory Service Manual For JLG Telehandler. Manual Contains Illustrations, Instructions, Diagrams For Step By Step Remove And Install, Assembly And Disassembly, Service, Inspection, Repair, Troubleshooting, Tune-Ups.

Format: PDF
Language: English
Pages: 230
Issue: april 2011
Bookmarks: Yes
Searchable: Yes
Wiring Diagrams: Yes
Hydraulic Diagrams: Yes

Model

JLG Telehandler
Skytrak 6036
SN 0160039338 & After including 0160024571 & 0160037911
Skytrak 6042
SN 0160039075 & After
Skytrak 8042
Skytrak 10042
Skytrak 10054
SN 0160029593 & After

Contents

-SAFETY PRACTICES
Introduction
Disclaimer
Operation & Safety Manual
Do Not Operate Tags
Safety Information
Safety Instructions
Safety Decals
-GENERAL INFORMATION AND SPECIFICATIONS
Replacement Parts and Warranty Information
Torque Charts
Specifications
Fluid and Lubricant Capacities
Service and Maintenance Schedules
Lubrication Schedules
-BOOM
Boom System Component Terminology
Safety Information
Boom System – Three Section (6036, 6042, 8042 & 10042)
Boom Assembly Maintenance
Boom System – Four Section (10054)
Boom Assembly Maintenance
Boom Extend and Retract Chains
Quick Attach Assembly
Boom Wear Pads
Boom Extend and Retract Chains
Forks
Troubleshooting
-CAB AND COVERS
Operator Cab and Covers Component Terminology
Operator Cab
Cab Components
Cab Removal
Cab Installation
-AXLES, DRIVE SHAFTS, WHEELS AND TIRES
Axle, Drive Shaft and Wheel Component Terminology (6036 & 6042)
Axle, Drive Shaft and Wheel Component Terminology (8042, 10042 & 10054)
General Information
Axle Assemblies
Axle Assembly and Drive Shaft Troubleshooting
Drive Shafts
Wheels and Tires
Brakes
Towing a Disabled Machine
-TRANSMISSION
Transmission Assembly Component Terminology
Transmission Serial Number
Transmission Specifications and Maintenance Information
Transmission Replacement
Transmission Troubleshooting
-ENGINE – CUMMINS QSB3.3T/QSB4.5T
Introduction
Engine Serial Number
Specifications and Maintenance Information
Engine Cooling System
Engine Electrical System
Fuel System
Engine Exhaust System
Air Cleaner Assembly
Engine Replacement
Isolation Coupler
Troubleshooting
-HYDRAULIC SYSTEM
Hydraulic Component Terminology
Safety Information
Hydraulic Pressure Diagnosis
Hydraulic Circuits
Hydraulic Reservoir
Hydraulic System Pump
Valves and Manifolds
Hydraulic Cylinders
-ELECTRICAL SYSTEM
Electrical Component Terminology
Specifications
Safety Information
Fuses and Relays
Electrical System Schematics
Engine Start Circuit
Charging Circuit
Window Wiper/Washer Windshield Wiper Motor
Cab Heater and Fan
Solenoids, Sensors and Senders
Display Monitor and Gauges
Dash Switches
Troubleshooting
-STABIL-TRAK SYSTEM AND BOOM INTERLOCK SYSTEM
Stabil-TRAK System Component Terminology
Boom Extend Interlock System Component Terminology (10054 Only)
Stabil-TRAK Description
Stabil-TRAK Electrical Circuit Operation and Troubleshooting (6042, 8042 & 10042)
Stabil-TRAK System Test
Stabil-TRAK Boom Interlock Electrical Circuit Operation and Troubleshooting (10054)
Boom/Outrigger Interlock System Test (10054)
Stabil-TRAK Hydraulic Circuit Operation and Troubleshooting

What you get

You will receive PDF file with high-quality manual on your email immediately after the payment.

Reviews

There are no reviews yet

Only logged in customers who have purchased this product may leave a review.
