Factory Technical Manual For John Deere 550B,555B Crawler Dozer, Crawler Loader. Illustrations, instructions, diagrams for Systems Diagnosis, Theory of Operation, Performance Testing, Tests and Adjustments, Operational Check, Unit Locations, Diagnostic Codes, Schematics and a lot of other useful information for service and repair remove and install, assembly and disassembly, inspection, troubleshooting, tune-ups.
Format: PDF
Language: English
Pages: 1058
Bookmarks: Yes
Searchable: Yes
Number: TM1331
Wiring Diagrams: Yes
Hydraulic Diagrams: Yes
Model
John Deere
550B
555B
Contents
– GENERAL INFORMATION
Introduction and Safety Information
General Specifications
Torque Specifications Chart for Cap Screws and Hydraulic Fittings
Lubrication
– TRACKS
Track Systems
Track Chain, Track frame, Track Carrier
Roller, Front Idler, Track Roller and Track
Adjuster
– AXLES AND SUSPENSION SYSTEMS
Axle Shaft, Bearings, and Reduction Gears
Final Drive, Steering Clutch, Brake Band,
Steering Clutch Housing and Linkage
– TRANSMISSION
Controls
Gears, Shafts, Bearings, Power
Shift Clutch, and Torque Converter
Hydraulic System
Oil Pump, Transmission Control Valve,
Selector Valve, Oil Filter
– ENGINE
Removal and installation
Crankshaft and Main Bearings
Camshaft and Valve Actuating Means
Connecting Rods and Pistons
Cylinder Block (Liners)
Engine Oiling System
Cylinder Head and Valves
Exhaust Manifold
Fuel Injection System
Engine Balancer
Turbocharger
Water Pump
Thermostats, Housing and Piping
Engine Oil Cooler
Fuel Filter
Fuel Transfer Pump
Starting System
Flywheel, Housing and Fasteners
– ENGINE AUXILIARY SYSTEMS
Cold Weather Starting Aids
Cooling Systems
Speed Controls
External Fuel Supply Systems
– TORQUE CONVERTER
Converter, Turbine, Gears, and Shafts (See Group 0350)
-STEERING SYSTEMS
Power.Steering
EQUIPMENT ATTACHING
Drawbar
-ELECTRICAL SYSTEM
Batteries, Support, and Cables
Alternator
Wiring Harness and Switches
Instruments and indicators
-FRAME, CHASSIS, OR SUPPORTING STRUCTURE
Frame Installation
Frame Bottom Guards
Chassis Weights
Sprocket, Rear, and Bottom Counterweights
-OPERATOR’S STATION
Operator Enclosure-ROPS, Cab, Windshield Wiper Motor, Operator Seat, and Backhoe Seat
-SHEET METAL
Hood or Engine Enclosure
Grille and Grille Housing, Engine Side
Shields, Cowl and Cowl Support
-WINCH
Controls Linkage
Winch Drive and Clutches
Winch Hydraulic System
Winch Control Valve and Hydraulic Pump
-LOADER
Buckets
Forks
Controls Linkage
Frames
Hydraulic System
Loader Cylinders, Hydraulic Pump and Loader Control Vslve
-BULLDOZER
Blades’
Controls Linkage
Frames
Hydraulic System
Hydraulic Return Filter, Reservoir, Pump,
Pump Drive, Dozer Control Valve, Auxiliary
Valve, Selector Valve, Flow Divider and
Bulldozer Cylinders
-BACKHOE 9300
Removal and Installation
Bucket
Controls Linkage
Frames
Hydraulic System
Control Valve, lift Check, Anti-Cavitation
Valve, Relief Valve, Manifold Block and
Backhoe Cylinders
-BACKHOE 9500
Removal and Installation
Bucket
Controls Linkage
Frames
Hydraulic System
Control Valve, Lift Check, Anti-cavitation
Valve, Relief Valve, Manifold Block and
Backhoe Cylinders
-LOG ARCH
Arch Frames
WINCH DRIVE
Gears, Shafts and Bearings
-GROUND CONDITIONING TOOLS
Teeth and Shanks
Frame
Hydraulic System
-OPERATIONAL CHECK OUT PROCEDURE
-ENGINE
Theory of Operation
System Operational Checks
Diagnostic Information
Adjustments
Tests
-ELECTRICAL SYSTEM
Theory of Operation
System Operational Checks
Diagnostic Information
Tests
-POWER TRAIN
Theory of Operation
System Operational Checks
Diagnostic Information
Adjustments
Tests
-HYDRAULIC SYSTEM
Theory of Operation
System Operational Checks
Diagnostic Information
Tests
-MISCELLANEOUS COMPONENTS
Theory of Operation
Diagnostic Information
Adjustments
Tests
-DEALER FABRICATED TOOLS
What you get
