Factory Repair Manual For John Deere Combine. Manual Contains Illustrations, Instructions, Diagrams For Step By Step Remove And Install, Assembly And Disassembly, Service, Inspection, Repair, Troubleshooting, Tune-Ups.
Format: PDF
Language: English
Pages: 1527
Issued: july 1997
Bookmarks: Yes
Model
John Deere Combine
9400
9500
9600
Contents
-GENERAL
Safety
Identification Number Location
Specifications
Tune Up and Adjustment
Fuels and Lubricants
-ENGINE
Remove and Install Engine
Cooling System
Lower Engine Repair
-FUEL AND AIR REPAIR
Air Intake System
Diesel Fuel System
-ELECTRICAL SYSTEM
Components
Bulbs and Switches
Batteries
Harness and Connector Repair
Gauges and Monitors
Wiper and Radio
Alternator
Starting Motor
Electrical Engine Control
-POWER TRAIN REPAIR
Transmission and Differential
Ring and Pinion Final Drive
Planetary Final Drive
Hydrostatic System
Cam Lobe Motor
Tires and Wheels
-POWER STEERING AND BRAKES
Steering
Brakes
-HYDRAULIC REPAIR
Hydraulic Reservoir
Hydraulic Pumps
Hydraulic Valves
Hydraulic Cylinders
Motors
Accumulator
Reel/Belt Pickup Pump Drive
-SEPARATOR SHELL
Gull Wing Doors
-OPERATOR STATION REPAIR
Air Conditioning System (R-12)—Type A
Air Conditioning System (R134A)—Type B
System Components
Cab
-FEEDER HOUSE REPAIR
Feeder House/Conveyor
Feeder House Conveyor Drum
Conveyor Shaft And Slip Clutch
Feeder House Drives And Reverser
Gear Case
Contour Master Platform
Driveshafts
Contour Master Tilt Cylinder
Contour Master Tilt Frame
Contour Master Feeder House
-SEPARATOR
Separator Repair
Cylinder Drives
Straw Walkers and Crankshafts
Straw Chopper, Straw Spreader and Chaff Spreader
Shoe Supply Augers, Cleaning Fan and Chaffer and Sieve Frame
Tailings Elevator and Augers
Primary Countershaft Gearcase
Header Electromagnetic Clutch
-GRAIN TANK AND UNLOADING SYSTEM REPAIR
Grain Tank Cross Augers
Unloading Auger System Drives
Vertical Unloading Auger and Lower Gearcase
Horizontal Unloading Auger and Gearcase
Upper Clean Grain Elevator
Grain Tank and Extensions
Clean Grain Elevator and Loading Auger Gear Case
-ENGINE GEARCASE AND CONTROL VALVE REPAIR
Engine Gearcase and Valve
-DIAL-A-MATIC HEADER HEIGHT CONTROL
Dial-A-Matic Header Height Control
-SUPPLEMENT-SIDEHIILL AND MAXIMIZER COMBINES
General
Power Train Repair
Hydraulic Repair
Operator Station Repair
Contour Master Feeder House Repair
Separator
Grain Tank and Unloading System Repair
Operation and Tests Electrical Diagnostics
