Kawasaki 50ZV Shop Manual Combined Wheel Loader manuals in PDF

Factory Shop Manual For Kawasaki Wheel Loader. Manual Contains Illustrations, Instructions, Diagrams For Step By Step Remove And Install, Assembly And Disassembly, Service, Inspection, Repair, Troubleshooting, Tune-Ups.

Format: PDF
Language: English
Quantity of Manuals: 2
Pages: 534; 189
Number: 93205-00070 (august 2004); (93205-00151; 93205-00151 june 2009)
Wiring Diagrams: Yes
Hydraulic Diagrams: Yes

Model

Kawasaki Wheel Loader
50ZV
Serial No. 50C3-0101 and up

Contents

-50ZV GENERAL INFORMATION
How to Use Manual
Outline
-50ZV MEASUREMENT FOR PERFORMANCE CHECK
Cautions on Safety
Standard Measurement Values for Performance Check
-50ZV FUNCTION & STRUCTURE CHASSIS GROUP
Front Chassis
Rear Chassis
Center Pin
-50ZV CHECK & ADJUSTMENT CHASSIS GROUP
Linkage Pin
Center Pin
-50ZV FUNCTION & STRUCTURE POWER GROUP
Power Line
Engine/Transmission
Radiator
Propeller Shaft
Axle Assembly
Axle Support
Differential Gear
-50ZV CHECK & ADJUSTMENT POWER GROUP
Engine
Propeller Shaft
Axle
-50ZV FUNCTION & STRUCTURE TORQUE CONVERTER AND TRANSMISSION GROUP
Torque Converter
Torque Converter Gear Pump
Transmission
Clutch Pack
Power Flow Path in the Transmission
Hydraulic System Diagram
Hydraulic Circuit Diagram
Oil Flow
Shift Lever
Control Valve
Modulation Mechanism
Accumulator
Solenoid Valve
-50ZV CHECK & ADJUSTMENT TORQUE CONVERTER AND TRANSMISSION GROUP
Clutch Oil Pressure
-50ZV FUNCTION & STRUCTURE HYDRAULIC GROUP
Flushing Hydraulic Circuit
Cautions on Hydraulic Parts Replacement
Hydraulic Circuit Symbols
Hydraulic System Operation
Layout of Hydraulic Units
Hydraulic Tank
Hydraulic Pump
Hydraulic Cylinder
Return Filter
Loading System
-50ZV CHECK & ADJUSTMENT HYDRAULIC GROUP
Loading/Steering Circuit Relief Valve
Valve Control
Hydraulic Cylinder
-50ZV FUNCTION & STRUCTURE BRAKE GROUP
Brake Units Layout
Brake Circuit
Hydraulic Servo Master Cylinder
Service Brake
Parking Brake
Brake Control
Brake Oil Reservoir
-50ZV FUNCTION & STRUCTURE ELECTRICAL GROUP
How to Use Electrical Wiring Diagram
Electrical Cable Color Codes
Electrical Circuit Symbols
Sensor Mount
-50ZV CHECK & ADJUSTMENT ELECTRICAL GROUP
Cautions Regarding Electric Circuit Check
Electrical Circuit Check
-50ZV FUNCTION & STRUCTURE OPERATOR STATION GROUP
Cabin (OPT)
Operator Seat
Air Conditioner (OPT)
-50ZV CHECK & ADJUSTMENT OPERATOR STATION GROUP
Air Conditioner
-50ZV DRAWING & DIAGRAMS
Axle Assembly
Torque Converter and Transmission
Loading/Steering Hydraulic Line
Brake Circuit
Electrical Wiring Diagram (1/2)
Electrical Wiring Diagram (2/2)
Electrical Connection Diagram
Electrical Wiring Diagram (CAB)
Electrical Equipment Layout
Electrical Circuit Diagram (Cabin Air Conditioner)
Electrical Wiring Diagram (Cabin Air Conditioner)
-CHASSIS GROUP
Disassembly & Reassembly
Service Standard
-POWER GROUP
Disassembly & Reassembly
Service Standard
-TORQUE CONVERTER & TRANSMISSION GROUP
Disassembly & Reassembly
Service Standard
-HYDRAULIC GROUP
Disassembly & Reassembly
Service Standard
-BRAKE GROUP
Disassembly & Reassembly
Service Standard
-OPERATOR STATION GROUP
Disassembly & Reassembly
Service Standard

What you get

You will receive PDF file with high-quality manual on your email immediately after the payment.
