Komatsu FB10-4 To FB18S-4 Shop Manual Forklift FB10-18.4-BE1 manuals in PDF

Factory Shop Manual For Komatsu Forklift. Manual Contains Illustrations, Instructions, Diagrams For Step By Step Remove And Install, Assembly And Disassembly, Service, Inspection, Repair, Troubleshooting, Tune-Ups.

Format: PDF
Language: English
Pages: 230
Number: FB10/18.4-BE1
Wiring Diagrams: Yes
Hydraulic Diagrams: Yes

Model

Komatsu Forklift
FB10-4
FB14-4
FB15-4
SN12001 And Up

FB18-4
SN10151 And Up

FB10S-4
FB14S-4
FB15S-4
SN 11001 And Up

FB18S-4
SN 10011 And Up

Contents

FOREWORD
-GENERAL AND SPECIFICATIONS
General View
Operator’s Compartment
Machine Serial Number
Specifications
-STANDARD TIGHTENING TORQUE
Tightening Torque For Bolts
Tightening Torque For Pipe Joints
-GENERAL DISASSEMBLY AND ASSEMBLY
Disassembly Diagram
Description Of The Symbols
Tightening Torque Of Main Nuts And Bolts
Weight Table
General Location Of Main Parts
General Disassembly And Assembly Flow Chart
Removal And Installation Of Units
-DISASSEMBLY AND ASSEMBLY OF COMPONENT
Power Train
Brake System
Steering System
Hydraulic System
-ELECTRICAL SYSTEM
Chassis Wiring Diagram
Motor
Controller
Function Of Controller
Adjusting Controller
Battery Charger
-TROUBLESHOOTING
Controller
Table Of Check Points And Voltage
Troubleshooting Categories
Battery Charger
Periodic Replacement Of Consumable Parts
Service Data
Lubrication Chart
Lubricants
Maintenance Table
Maintenance Of Electrical Parts

What you get

You will receive PDF file with high-quality manual on your email immediately after the payment.
