Factory Shop Manual For Komatsu Electric Lift Truck. Manual Contains Illustrations, Instructions, Diagrams For Step By Step Remove And Install, Assembly And Disassembly, Service, Inspection, Repair, Troubleshooting, Tune-Ups.
Format: PDF
Language: English
Pages: 146
Number: FB20SH-30SH.4-BE1
Hydraulic Diagrams: Yes
Model
Komatsu Electric Lift Truck
FB20SH-4
FB25SH-4
FB30SH-4
SN 30001A And Up (USA Type-UL Specification)
SN 30001 And Up (STD Type-General Export Specification)
Contents
FOREWORD
-GENERAL AND SPECIFICATIONS
Overall Dimensions And Specifications
Weight Of Main Components
Standard Tightening Torque For Bolts
Standard Tightening Torque For Pipe Joints
Periodical Replacement Of Safety-Assuring Parts
General Locations
Instruments And Controls
-REMOVAL AND INSTALLATION OF UNITS
Locations Of Units
How To Install Units
Removal And Installation Flowchart
Removal And Installation Of Units
-DISASSEMBLY AND ASSEMBLY OF COMPONENTS
Power Train
Brake System
Steering System
Hydraulic System
Mast
-ELECTRICAL SYSTEM
Electrical Components
Battery And Case (For USA)
Motors
-TESTING AND ADJUSTING
Motor
Battery
Controller
Travel System
Steering System
Brake System
Work Equipment System
Adjustment Of Parking Brake Lever
Adjustment Of Brake Pedal
Adjustment Of Accelerator Pedal
Adjustment Of Operator’s Seat Switch
-CONVERSION TABLE
Millimeters To Inches
Inches To Millimeters
Cubic Meters To Cubic Yards
Cubic Yards To Cubic Meters
Liter To US Gallon
US Gallon To Liter
Liter To UK Gallon
UK Gallon To Liter
Kilogram To Pound
Pound To Kilogram
KG/CM2 To LB/IN2
KGM To FT LB
Temperature
What you get
You will receive PDF file with high-quality manual on your email immediately after the payment.
