Komatsu PC360LC-10 PC390LC-10 Shop Manual Hydraulic Excavator CEBM025204 manuals in PDF

Factory Shop Manual For Komatsu Hydraulic Excavator. Manual Contains Illustrations, Instructions, Diagrams For Step By Step Remove And Install, Assembly And Disassembly, Service, Inspection, Repair, Troubleshooting, Tune-Ups.

Format: PDF
Language: English
Pages: 1998
Number: CEBM025204 (february 2013)
Bookmarks: Yes
Searchable: Yes
Wiring Diagrams: Yes
Hydraulic Diagrams: Yes

Model

Komatsu Hydraulic Excavator
PC360LC-10
SN A32001 And Up; K64001 And Up
PC390LC-10
SN A30001 And Up

Contents

-FORWORD
Safety
General
How To Read The Shop Manual
Hoisting Instructions
Handling Electric Equipment And Hydraulic Components
Push Pull Coupler
Explanation Of Maintenance Standard Terms
Handling Of Fuel System Devices
Handling Of Intake System Parts
Standard Tightening Torque
Electric Wire Code
Precautions For Operations
Conversion Tables
Coating Materials
List Of Abbreviations
-GENERAL
Specification Dimension Drawings
Specifications
Weight Table
Fuel, Coolant And Lubricants
-STRUCTION AND FUNCTION
Engine And Cooling System
Powertrain
Undercarriage And Frame
Hydraulic System
Work Equipment
Cab And Its Attachments
Electrical System
Machine Monitor System
Komtrax System
Sensors
-STANDARD VALUE TABLES
Standard Value Table for Engine Related Parts
Standard Value Table for Chassis Related Parts
Posture of Machine for Measuring Performance and Measurement Procedure
-TESTING AND ADJUSTING
General Information
Engine And Cooling System
Powertrain
Undercarriage And Frame
Hydraulic System
Cab And Its Attachments
Electrical System
PM Clinic
-TROUBLESHOOTING
General Information On Troubleshooting
Diagnostic Procedure For Wiring Harness Open Circuit Of Pressure Sensor System
Failure Code (Display Of Code)
Electrical System (E-Mode)
Hydraulic And Mechanical System (H-Mode)
Engine (S-Mode)
-DISASSEMBLY AND ASSEMBLY
Special Tools List
Connector Repair Procedures
Engine And Cooling System
Powertrain
Undercarriage And Frame
Hydraulic System
Work Equipment
Cab And Its Attachments
Electric System
-MAINTENANCE STANDARD
Engine And Cooling System
Powertrain
Undercarriage And Frame
Hydraulic System
Work Equipment
-AIR CONDITIONER
Air Conditioner
-DIAGRAMS AND SCHEMATICS
Hydraulic System
Electrical System

What you get

You will receive PDF file with high-quality manual on your email immediately after the payment.
