Factory Operators Manual For New Holland Tractor. Manual For Owners And Operators. It Contains Important Information And Instructions For Maintenance Description Of The Functions And Capabilities Of The System. Description Of Possible Faults / Problems And Their Solution.
Format: PDF
Language: English
Pages: 176
Number: 87021351 (december 2002)
Bookmarks: Yes
Searchable: Yes
Model
New Holland Tractor
TN55
TN65
TN70
TN75
For Tractors After Serial Number 1268128
Contents
-GENERAL INFORMATION, CONTROLS AND INSTRUMENTS
General Information, Controls And Instruments
Introduction
Safety Covers And Guards
Controls And Instruments
Dashboard And Instrument Panel Controls
Right-Hand Side Operating Controls
Left-Hand Side Controls
Towing The Tractor
Loading The Tractor Onto A Transporter
Checks Before Using The Tractor
-OPERATING INSTRUCTIONS
Before Using The Tractor
Operating Instructions
Instrument Panel
Non-Synchronized Mechanical Shuttle Or Synchro Command Mechanical Shuttle Transmission 30 Km/H (1864 Mph) (8F+8R)
Synchro Command Mechanical Shuttle Transmission
Mechanical Shuttle Lever (8F+8R) (16F+16R)
Synchro Command Electro-Hydraulic Power-Shuttle Transmission 30 Km/H (18.64 Mph) (8F+8R)
Synchro Command Electro-Hydraulic Power-Shuttle Transmission 30 Km/H (18.64 Mph) (16F+16R)
Electro-Hydraulic Power-Shuttle (8F+8R) (16F+16R)
Mechanically Controlled Four-Wheel Drive
Differential Lock
Brakes
Power Take-Off
Independent Power Take-Off Operated By The Engine
Mechanically Controlled Hydraulic Lift
Three-Point Linkage
Towing Equipment
Implement Hitch Points 2WD Or 4WD
Foldable ROPS
Rear Remote Control Valves
Joystick Control (Optional)
Wheel Track Adjustment
Steering Angle Adjustment
Tires
Tire Combinations
Metal Ballasting
Maximum Permitted Weights
Seat Adjustment
-LUBRICATION AND MAINTENANCE
Introduction
Running In Period
Tractor Refueling
Miscellaneous Checks
Access For Inspection And Maintenance
Lubrication And Maintenance Table
Flexible Maintenance
When The Indicator Light Illuminates On The Instruction Panel
Every 10 Hours Of Work
Every 50 Hours Of Work
Every 300 Hours Of Work
Every 900 Hours Of Work
Every 1200 Hours Of Work Or Every Year
Every 1200 Hours Of Work Or Every 2 Year
Flushing The System
General Maintenance
Bleeding The Fuel System
Bleeding The Brake Fluid Circuit On 2WD Models
Electrical System
Recommendations For Bodywork Maintenance
Prolonged Tractor Inactivity
Fuel And Lubrication Specifications
-TROUBLESHOOTING
Troubleshooting
Locating And Identifying Problems
Engine
Electrical System
Hydraulic System
Hydraulic Lift And Three Point Linkage
Brakes
-SPECIFICATIONS
Specifications
Dimensions Of 2-WD TN55, TN65, TN70 And TN75 Models With Roll Bar
Dimensions Of 4-WD TN55, TN65, TN70 And TN75 Models With Roll Bar
Ballast Kg (Lbs)
Tractor Weights With Roll Bar
Engine
Mechanically Controlled Hydraulic Lift
Steering
Electrical System
-PRE—DELIVERY INSPECTION
-SERVICE AFTER THE FIRST 50 HOURS OF WORK
What you get
You will receive PDF file with high-quality manual on your email immediately after the payment.
Anonymous (verified owner) –
Excellent product clarity and online delivery is instantaneous.
