Factory Workshop Manual For Perkins Peregrine 1300 Series engine. Tons of illustrations, instructions, diagrams for step by step remove and install, assembly and disassembly, service, inspection, repair, troubleshooting, tune-ups.
Format: PDF
Language: English
Pages: 310
Number: TPD01921307
Searchable: Yes
Model
Perkins Peregrine, 1300 Series
Peregrine 6 cylinder diesel engines for automotive applications
1300 Series 6 cylinder diesel engines for agricultural and industrial applications
Contents
-INTRODUCTORY
Introduction
Safety Precautions
Asbestos
Engine Identification
General Features
Engine Systems
-TURBOCHARGERS
Typical Turbocharger And Common Parts
Exploded View (T04E-17)
Special Torques
General Operation
Removal And Reassembly
Installation
Reconditioning
Troubleshooting
-MANIFOLDS
Exploded View
Special Torques
Special Service Tools
Exhaust Manifold
Intake Manifold
-CYLINDER HEAD AND VALVES
Exploded View
Special Torques
Special Service Tools
Cylinder Head Removal
Cylinder Head Inspection
Cylinder Head Reconditioning
Cylinder Head Reassembly
Cylinder Head Installation
-ROCKER ARM ASSEMBLY, CAMSHAFT, TAPPETS & PUSH RODS
Exploded View
Special Torques
Special Service Tools
Rocker Arm Assembly
Camshaft, Tappets & Push Rods
-CONNECTING RODS, PISTONS, RINGS AND SLEEVES
Exploded View
Special Torques
Special Tools
Connecting Rods, Pistons, Rings And Sleeves
-VIBRATION DAMPER, CRANKSHAFT, MAIN BEARINGS, FLYWHEEL AND CRANKCASE
Exploded View
Special Torques
Special Service Tools
Rear Oil Seal & Wear Sleeve (Removal And Reassembly)
Flywheel (Reconditioning)
Oil Level Gauge Tube Assembly (Removal And Reassembly)
Damper, Crankshaft And Main Bearings (Reconditioning)
Crankcase (Reconditioning)
Damper, Crankshaft And Main Bearings
Crankcase Breather
-TIMING GEAR TRAIN AND FRONT COVER
Exploded View
Special Torques
Special Tools
Engine Gear Train Timing
Front Cover
Timing Gear Train
Front Cover
Injection Pump Drive Gear
-LUBRICATING OIL PUMP, OIL FILTERS AND COOLER
Exploded Views
Special Torques
Special Service Tools
Lubricating Oil Pump
Oil Filters And Header
Oil Cooler And Coolant Filter Assembly
Oil Pressure Regulator Valve
Oil Pickup Tube
-WATER PUMP AND THERMOSTAT
Exploded View
Special Torques
Service Tools
Water Pump
Thermostat
-FUEL INJECTION PUMP
Exploded Views
Special Torques
Special Service Tools
Fuel Injection Pump
-NOZZLES
Exploded View
Special Torques
Service Tools
Nozzles
-APPENDIX INDEX
General Engine Specifications
Component Specifications
Torque Data
Special Service Tools
Conversion Table (English/Metric)
What you get
You will receive PDF file with high-quality manual on your email immediately after the payment.
