Takeuchi TB1160W Operators Manual Hydraulic Excavator 514300004- manuals in PDF

Factory Operators Manual For Takeuchi Hydraulic Excavator. Manual For Owners And Operators. It Contains Important Information And Instructions For Maintenance Description Of The Functions And Capabilities Of The System. Description Of Possible Faults / Problems And Their Solution.

Format: PDF
Language: English
Pages: 258
Issue: july 2011
Bookmarks: Yes
Searchable: Yes

Model

Takeuchi Hydraulic Excavator
TB1160W
Serial No. 514300004-

Contents

-SAFETY ALERT SYMBOL
Signal Words
Introduction
Machine Description
Notes On Reading This Manual
-SAFETY
General Precautions
Precautions When Preparing
Precautions When Starting
Precautions When Operating
Precautions When Stopping
Precautions When Transporting
Precautions On Maintenance
Safety Signs (Decals)
-CONTROLS
Names Of Components
Covers
Cab
Seat And Seat Belt
Multi-Information Display
Control Console
Switches
Levers And Pedals
Air Conditioner
Accessories
Radio (For Cab)
Auxiliary Hydraulic Lines
-OPERATION
Before Starting Operation
Starting And Stopping The
Operating The Machine
Operating Procedures
Parking The Machine
Handling In Cold Climates
Handling Tires
-TRANSPORT
Loading And Unloading
Hoisting The Machine
Securing The Machine
Precautions To Be Taken During Transportation
-MAINTENANCE
General
Service Data
Safety-Critical Parts
Maintenance List
Walk-Around Inspection
Daily Inspection (Every 10 Hours)
After The Initial 50 Hours (Only For New Machines)
Every 50 Hours
After The Initial 250 Hours (Only For New Machines)
Every 250 Hours
Every 500 Hours
Every 1000 Hours
Every 2000 Hours
Every 4000 Hours
When Required
-TROUBLESHOOTING
Symptoms That Are Not Malfunctions
If The Engine Overheats
If The Battery Goes Dead
If A Fuse Blows
Restarting After Adding Fuel
If A Warning Lamp Flashes
Error Code List
Other Symptoms
Lowering The Boom To The Ground
Towing
-SPECIFICATIONS
Basic Specifications
Basic Specifications (Serial No. 514300051 ~)
Machine Dimensions
Operating Ranges
Lifting Capacities
-OPTIONS
General Precautions
Hydraulic Breaker
Load Safety Device
Fuel Supply Pump
Outrigger
Air Suspension Seat
EC-CONFORMITY CERTIFICATE

What you get

You will receive PDF file with high-quality manual on your email immediately after the payment.
