Factory Operators Manual For Tigercat Feller Buncher. Manual For Owners And Operators. It Contains Important Information And Instructions For Maintenance Description Of The Functions And Capabilities Of The System. Description Of Possible Faults / Problems And Their Solution.
Format: PDF
Language: English
Pages: 427
Number: 47842AENG (november 2019)
Bookmarks
Searchable
Model
Tigercat Feller Buncher
X870D
LX870D
Serial Number 87063501 To 87065000
Serial Number 87073501 To 87075000
Contents
-INTRODUCTION
Machine Identification And Serial Numbers
Standards ROPS, TOPS, FOPS, OPS
Non-Approved Field Product Changes
Regulatory Information
-SAFETY
Avoid Injury From Backover Accidents
Battery Safety
Cab Exits
Cable Assist
Cooling System
Diesel Exhaust Fluid (DEF)
ER Boom System
ER Boom System Precautions
Felling Trees
Fire Prevention
Fluid Injection Injury
General Safety Precautions
Grease Injection Injury
Hazard Zone
Hydraulic Pressure Hazard
Lightening Safety Awareness
Loose Clothing Hazard
Machine Stability And Traction
Operating Safety Precautions
Parking The Machine
Protective Clothing
Safety Interlock Switches On Cab Doors
Safety Precautions, Servicing
Servicing Safety Precautions
Welding, Prior To
Wet Chemical Cleanup Procedure
Working With Oil
-USING HIGH-SPEED DISC SAWS SAFELY
Comments And Instructions
Dangers
Foreword
Housing Types
Saw Head Do Nots
Type Of Housing Makes A Difference
-CONTROLS AND OPERATION
A/C/Defrost Switch
Air Source Switch
Alarm
Attachment, Instructions And Precautions
Auxiliary Input
Auxiliary Power Outlet, 12 V
Battery Boosting
Battery Disconnect Switch
Belt Routing, Serpentine
Boom Controls
Cab Dome Light Switch
Camera
Cold Weather Starting
Computer
Computer And Display
Computer Display-Home Screen
Computer Display Messages
Control Panel
Control Panels
Controls
Coolant Shut-Off Valves
Coolant Shut-Off Valves, Engine
Cooling Fan Switch
Current Output Channels
Display, Video
Electronic Device Holder
Emergency Exits
Engine, Restarting After Engine Runs Out Of Fuel
Engine Speed Switch
Engine, Stopping
ER Boom System, Instructions
Fan Service Mode
Fan Speed Switch
Filters
Fire Extinguisher, Cab
Fire Extinguisher, Portable
Fire Suppression System
Fire Suppression System Type A
Fire Suppression System Type B
Fuel, Refuelling Procedure
Fuel Tank
Heat/Cool Temperature Knob
Heater Control Panel Engine Coolant (Optional)
Horn/Safety Alert Switch
Joysticks Controls
Key Switch
Lights
Load Sensing, Operating Tips
Operating The Machine
Operating Tips With Load Sensing
Operation Modes
Operator’s Manual
Operator’s Manual Case
Operator’s Seat
Pictograms
Pilot System Off, Push Button Switch
Pilot System Off Switch
Pilot System Reset Switch
Power Roof Switch
Power Side Door Switch
Radio
Rearview Camera
Refuelling Procedure
Saw Switch
Serpentine Belt Routing
Service Work Light Switch And Indicator Light
Skyview Camera
Slope Indicators
Starting Engine
Storage Area
Swing Brake Switch
Swing Control, Joystick
Switch
System Test And Warm Up
Telematics Repair Mode
Track Drive Controls
Track Range (High/Low) Switch
Travelling, Boom Raised
Travel Speed Control
USB Connection
Video Display, Camera
Warm Up Mode
Work Light Switches
-LUBRICATION AND MAINTENANCE
Adding Engine Coolant
Aftertreatment System
Aftertreatment System (Denox 22 System, Tier 4F)
Air Cleaner Housing
Air Conditioning System
Air Filters
Air Intake System
Anti-Corrosion Spray, Removal, If Applicable
Approved Anti-Seize Pastes For Exhaust/Aftertreatment Sensors
Approved Hydraulic Oils
Battery Box Cover
Battery Care
Care Of Polycarbonate Windows
Care Of The Machine
Check Engine Coolant Level
Cleaning
Cleaning Cooler Package
Clean Out Cover
Clean Out Cover
Commercial Wood-Weights
Cooler Package-Cleaning
DEF (Diesel Exhaust Fluid, Tank
Diagnostics Connection, Engine
Diesel Exhaust Fluid (DEF)
Diesel Exhaust Fluid (DEF) Handling And Storage
Diesel Exhaust Fluid (DEF) Tank
Diffusers
Diffusers/Strainers – Hydraulic Oil Return
Draining Engine Coolant
Draining Hydraulic Oil Tank
Emergency Exit-Maintenance Guide
Emergency Exits, Check Monthly
Enclosure Access Door
Engine Bottom Access Cover
Engine Diagnostics Connection
Engine Oil Drain Plug Access Cover
ER Boom System
Filling The DEF Tank
Filters
Fire Prevention
Fluid Analysis Program
Fluid Sampling Program
Fuel Cooler
Fuel Heater
Fuel System
Fuel Tank
Fuel Tank Drain Plug Bottom Access Cover
Fuses And Relays
Graffiti Removal
Hydraulic Adjustments Table
Hydraulic Oil Fill Pump
Hydraulic Oil Level Sight Gauges
Hydraulic Oil Tank
Hydraulic Oil Tank Breather
Hydraulic Oil Tank Pressurization Instructions
Hydraulic Oil Tank Vacuum System (If Equipped)
Hydraulic Pump Compartment Bottom Access Cover
Hydraulic System
Leveler Cylinder Locks
Machine Parameters
Main Control Valve Bottom Access Cover
New Machine Maintenance
Oil Lost From Leakage
Power Roof
Power Side Door
Power Unit
Pressure And Speed Settings
Pressure Washing
Preventive Maintenance Schedule
Pump Case Drain Filter
Pump Cover
Pump Cover Side Door
Pump Drive Gearbox
Rear Door
Refilling The Hydraulic System
Remote Fuel Tank, Coolant Heater Unit (Optional)
Rotary Manifold Seal Lubrication
Scheduled Maintenance
Serpentine Belt, Inspection Replacement
Service And Lubrication Schedule
Service And Maintenance Access Doors And Covers
Service Compartment Bottom Access Cover
Strainers, Case Drain
Swing Drive Gearbox Lubrication
Telematics System
Telematics System Components
Temperature Sender
Timed Purge Interval
Torque Chart, General
Torque, Fluid Connections
Track
Track Chain
Track Components
Track Drive Gearbox
Track Motor Cover
Track Operation And Wear Prevention
Track Sag Adjustment
Weights Of Commercial Wood
Windows
Wood, Weights Of Commercial Wood
PRESSURE AND SPEED SETTINGS
-TIGERCAT 800D 800E MOVING AND TRANSPORTING INSTRUCTIONS FELLER BUNCHER 44821AMUL
Transporting Instructions
Vehicle Moving Instructions
