Factory Service Manual For Vibromax Trench Roller. Manual Contains Illustrations, Instructions, Diagrams For Step By Step Remove And Install, Assembly And Disassembly, Service, Inspection, Repair, Troubleshooting, Tune-Ups.
Format: PDF
Language: English
Pages: 116
Number: SM35002 (October 2003)
Searchable: Yes
Wiring Diagrams: Yes
Hydraulic Diagrams: Yes
Model
Vibromax Trench Roller
W1500
Serial No. starting at JKC4200800
Contents
-GENERAL INFORMATION
Machine Identification
Machine Description
Machine Serial Numbers
Component Identification
Safety
General Information
Standard Torque Data
Metric/USA Conversions
Machine Specifications
Fluid Capacity
Diesel Fuel Specification
Engine Oil Specification
Machine Controls, Manual
Machine Controls With Remote
Remote Battery Charger
Starting The Engine
Parking Brake
Machine Operation
Parking
Turning Off The Engine
Maintenance Schedule
-ENGINE
Engine Overhaul
Kubota Engine Warranty
Oil And Filter Change
Air Filter System
Engine Cooling System
Engine Fuel System
-ELECTRICAL CIRCUITS
ELECTRICAL SYSTEM
Understanding Electrical Schematics
Understanding Relays
Engine Electrical Circuits
Understanding Batteries
Starter System Diagnostics
Machine Electrical Circuits
Electrical Layout
Electrical Schematics
Wire Harness 5731/82110
Wire Chart 5731/82110
Wire Harness 5731/82505
Wire Chart 5731/82505
Wire Harness 5731/82121
Wire Chart 5731/82121
Wire Harness 5731/82105
Wire Chart 5731/82105
Wire Harness 5731/82175
-HYDRAULIC SYSTEMS
Identifying Hydraulic Components
Suction Lines
Propulsion System Drawings
Vibration System Drawings
High Speed Travel Drawings
Brake System Drawings
Drain Line Drawings
Hydraulic Test Ports
Hydraulic Schematic
-CHASSIS
Lower Frame
Upper Frame
Vibration Shaft
Vibration System
