Factory Operators Manual For Zetor Tractor. Manual For Owners And Operators. It Contains Important Information And Instructions For Maintenance Description Of The Functions And Capabilities Of The System. Description Of Possible Faults / Problems And Their Solution.
Format: PDF
Language: English
Pages: 108
Number: 222.213.586 (october 2020)
Searchable
Model
Zetor Tractor
Compax HT25
Contents
-LOCATION OF SERIAL NUMBERS
Product Warranty
ABOUT THIS MANUAL
-INTRODUCTION & DESCRIPTION
Instructions and Description
Description
-ROPS (ROLL OVER PROTECTION STRUCTURES)
Roll-Over Protection Structure (ROPS)
ROPS damage
Sliding Seat
Seat Suspension Adjustment
-SAFETY INSTRUCTIONS, DO’S & DON’TS
Introduction To Safety Information
Signal Words
Introduction To Safety Instructions Introduction To Safety Instructions
Protection Children
Use Of ROPS And Seat Belt
Precaution To Avoid Tipping
Safe Parking Of The Tractor
Keep Riders Off Tractor
Handle Fuel Safely-Avoid Fires
Stay Clear Of Rotating Shafts
Always Use Safety Lights And Devices
Practice Safe Maintenance
Avoid High-Pressure Fluids
Prevent Battery Explosions
Prevent Acid Bums
Battery Disconnect
Service Tractor Safely
Work In Ventilated Area
Tractor Runaway
Safety Starter Switch
Emergency Exits
Safety Precautions When Using The Loader
Towing Safely
Operator Protective Structure (Ops)
Use Of Hazardous Substances
Safe Operation Of Your Tractor
Safety Tips During Maintenance
Mounting And Demounting Implements
The Following Precautions Are Suggested To Help Prevent Accidents
Diesel Fuel
Do’s And Don’t’s
Do’s-For Better Performance
Don’ts – For Safe Operation
-SAFETY SIGNS
General Safety Information
Plates On The Instrument Panel Cover
Plates On The Chassis
Plates Around The Seat
UNIVERSAL SYMBOLS
-CONTROLS, INSTRUMENTS & OPERATIONS
Description of Tractor Controls
Instruments and Switches
Main Switch (Key Switch)
Headlights Switch (Beacon Light), Turn Signal Lights Switch and Horn Switch
Hazard Warning Lights Switch
Hour Meter
Tachometer
Fuel Gauge
Instrument Panel Indicator Lights
PTO Indicator Light
PTO ON/OFF Switch
Tractor Controls
Throttle Lever (Manual Control)
Brake Pedal
Handbrake Lever
Cruise Control Lever
Travel Direction Pedals
Range Shift Lever (Road / Reduced)
Differential Lock Pedal
Front Axle Drive Lever (4Wd)
Driver’s Seat
Driver’s Seat Adjustment
PTO
Rear PTO
Mid PTO
Hydraulics Operation
Hitch Control Lever
Three-Point Hitch Lowering Speed Control
Three-Point Hitch Control (TPH)
Stabilizer Chain Adjustment
Lift Link Adjustment
Link Yoke Adjustment On Lower Link
Implement Installation
Towing Equipment
Implements Connection And Disconnection
Connection
Disconnection
Implement Installation
Front Loader Mounting Points
Tractor Steering
Pre-Departure Check
Starting The Engine
Warming Up
Warming Up In Cold Weather
Warming Up Time
Stopping The Engine
Stopping And Parking
Storage Of The Engine In Operating Conditions For 3 Months Or Longer
Service Braking And Parking
Drive Off On Steep Slope
Driving Downhill
Check During Driving
Fuel Gauge
Engine Coolant
-MAINTENANCE INSTRUCTIONS
Checks and Service
Pre-Start Checks
Engine Coolant
Engine Oil
Transmission Oil
Fuel
Fuel Saving
Tire Pressure
Steering
Brake
Electrical
Loader Installation
Loader Disconnection (Loader Valve or Loader Port)
Maintenance and Adjustment Schedule
Periodical Check and Service Table
Filling Scheme and Quantity Table
Recommended ZETOR service fillings
How to Open Covers
Hood Opening
Opening The Side Cover
Fuel
Fuel System Bleeding
Fuel Filter Cleaning
Oil And Water Separator Cleaning
Changing The Oils In The Tractor
Engine Oil Replacement
Transmission Oil Replacement
Front Axle Oil Replacement
Cleaning And Replacing Filters
Engine Oil Filter
Anti Freeze
Refrigerant Replacement
Greasing The Tractor
Setting The Play Of Controls
Adjusting The Brakes
Adjustment Method
Adjusting The Throttle Lever
Adjusting Toe-In
Battery Maintenance
Checking The Battery
Battery Maintenance
Battery Charging
Battery Disconnect
Removal Of The Knob
Refitting The Knob
Fan Belt Adjustment
Air Filter Service
Air Filter Dust Valve Cleaning
Element Cleaning/Replacement
Checking Hoses And Lines
Checking The Wiring Harness And Fuses
Replacing Fuses
Main Fuses
Fuse Box
Maintenance
Service Before Daily Or Short Term Storage
For Daily Or Short Term Storage
Long-Term Storage
Re-Use After Long Term Storage
-MAIN TECHNICAL PARAMETERS
Specifications
Weights And Tires
Maximum Ground Speed According To Tire Type
Noise Levels
Vibrations Related To Operator’s Seat
-TROUBLESHOOTING
Tractor Lifting
Towing the Tractor
Towing with the Engine Running
Towing with the Engine Off
