Factory Operators Manual For New Holland Tractor. Manual For Owners And Operators. It Contains Important Information And Instructions For Maintenance Description Of The Functions And Capabilities Of The System. Description Of Possible Faults / Problems And Their Solution.
Format: PDF
Language: English
Quantity of Manuals: 3
Pages: 466; 450; 440
Number: 51593959 (march 2019); 51594047 (march 2019); 51594048 (march 2019)
Bookmarks: Yes
Searchable: Yes
Model
New Holland Tractor
T5.75
T5.85
T5.95
T5.105
T5.115
PIN HLRT5095HHLE00237 and above
Contents
-GENERAL INFORMATION
Note To The Owner
Intended Use
Electro-Magnetic Compatibility (EMC)
Manual Scope And Required Training Level
Metric And Imperial Units Abbreviations
Identification Plates
Approval Data Plate
Operator’s Manual Storage
Machine Orientation
Health And Safety Related Standards Applied To Your Tractor
Exhaust Gas Recirculation (EGR) System
-SAFETY INFORMATION
Safety Aspects In Accordance With Regulation (EU) 1322/2014 – Annex XXII And Subsequent Amendments And Modifications
Safety Rules And Signal Word Definitions
Safety Rules
Safety Rules
Safety Rules – General Information
Safety Rules – Maintenance
Safety Rules – Wheels And Tires
Safety Rules – Explosions And Fires
Safety Rules – Fire Extinguisher
Safety Rules – Battery
Safety Rules – Passenger Seat
Safety Rules – Operator Presence System
Safety Rules – Power Take-Off (PTO)
Safety Rules – Reflectors And Warning Lights
Safety Rules – Seat Belts
Safety Rules – Operator Protective Structure
Safety Rules – HVAC System
Safety Rules – Personal Protective Equipment (PPE)
Safety Rules – “Do Not Use” Sign
Safety Rules – Hazardous Chemicals
Safety Rules – Near Utilities
Safety Rules – In The Event Of Electrical Storms
Safety Rules – Mounting And Dismounting The Machine
Safety Rules – Lifting And Overhead Loads
Safety Rules – Front End Loader
Ecology And The Environment
Noise Level
Vibration Levels
Machine Stability
Towing The Tractor For Recovery
Tractor Jacking Points
Burn Prevention
Emergency Escape From Cab
Wheel Chocks
Safety Signs
-CONTROLS AND INSTRUMENTS
Access To Operator’s Platform
Operator’s Seat
Passenger Seat
Forward Controls
Left-Hand Side Controls
Right-Hand Side Controls
Display
Warning And Advisory Symbols
-OPERATING INSTRUCTIONS
Commissioning The Unit
Starting The Unit
Stopping The Unit
Moving The Unit
-TRANSPORT OPERATIONS
Road Transport
Recovery Transport
-WORKING OPERATIONS
General Information
Drive
Rear Remote Control Valves
Mid-Mount Control Valve
Rear Power Take-Off (PTO)
Front Power Take-Off (PTO)
Rear Hydraulic Lift
Front Hydraulic Lift
Rear Three-Point Hitch
Front Three-Point Hitch
Towbar
Towing Hook
Trailer Braking Systems
Tires And Wheels
Tread And Fender Settings
Ballasting
Power Sockets
-MAINTENANCE
General Information
Maintenance Planning
As Required
At Warning Message Display
Every 10 Hours Or Daily
After The First 50 Hours Of Operation
Every 50 Hours
Every 100 Hours
Every 300 Hours
Every 600 Hours
Every 1200 Hours Or Annually
Every 1200 Hours Or Two Years
Every Two Years
Every 3600 Hours Or Four Years
Electrical System
Fuse And Relay Locations
Storage
Calibration
-TROUBLESHOOTING
Fault Code Resolution
Symptom(S)
-SPECIFICATIONS
General Dimensions
Maximum Permitted Loads On Front And Rear Axle
Maximum Permitted Loads On Drawbar
Maximum Permitted Loads On Towing Hitch
Speed Table For 12 X 12 Gearbox
Speed Table For 20 X 20 Gearbox
Speed Table For 24 X 24 Gearbox
Speed Table For 24 X 24 Gearbox
Speed Table For 40 X 40 Gearbox
Additional Equipment Attachment Points
Consumables
Capacities
General Specification
-ACCESSORIES
Radio
Single Piece Ballast
Coolant Immersion Heater (Where Fitted)
Front-End Loader Fixation Points
